Home > Products > Temperature Instruments > Handheld IR Infrared Thermal Imager Imaging Camera 80x60 2.5'' TFT LCD UTi100
Handheld IR Infrared Thermal Imager Imaging Camera 80x60 2.5'' TFT LCD UTi100
USD $1,700 - $1,800
/ Piece
1 Piece(Min.Order)
- 5 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Handheld Infrared Thermometers UNI-T UT302D Industrial temperature gauge Non-contract Digital IR Thermometer Gun -32 - 1050
-
Handheld Infrared Thermometers UNI-T UT302A Industrial temperature gauge Non-contract Digital IR Thermometer Gun -32 - 450
-
UNI-T UTi160B Portable Infrared Thermal Imager Imaging Clearly Industry 3.5 TFT Screen Camera
-
Portable Infrared Thermal Imager UNI-T UTi160B Imaging Clearly Industry Temperature Meter
-
Best AZ8866 non-contact digital infrared thermometer IR Thermometer Temperature with -20~420 degree
-
AZ8868 Infrared AZ-8868 Thermometer,8868 Gun Type IR Thermometer
Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UTi100 | Usage | Industrial | |
| Theory | Other, Infrared Thermal Imager | Accuracy | ±2°C or 2% readings | |
| Temperature Range | -20-300 |
Product Description
Handheld IR Infrared Thermal Imager Imaging Camera 80x60 2.5'' TFT LCD UTi100
Specifications:
Thermal Imager | UTi100 |
Basic Function | Technical Parameters |
View field angle/Min. imaging distance | 12°x9.4°/0.1m(can select other lens ) |
Temperature Sensitivity | 0.08°C , 30°C |
Detector Type | Uncooled Focal Plane Detector |
Resolution | 80*120 |
Waveform Length | 8-14um |
Focus | Manual adjustment |
Spacial Resolution | 2.2mrad |
Imaging Model | IR(iron red,anti-iron-red,black hot,white hot,colourful,feather red) |
LCD Display | 2.5'' TFT LCD |
Special Function | |
Video Output | PAL(50Hz) or NTSC(60Hz)combined video |
Temperature Range | -20°C~300°C |
Accuracy | ±2°C or 2% readings |
Temperature Measurement Model | The center point of measurement temperature or Full screen automatic catch Max./Min. temperature |
Settings | Language/Time/Fake Color/Unit |
Temperature Correction | Environment Temperature/Radiation rate/Humidity /Distance/Corrected Temperature |
Type | 2GB SD card, support Max.16GB |
File format | .UIR |
Alert Setting | Yes |
Battery/Working hours | Li-battery/2.5 hours |
Power Save Mode | Sleep Mode |
Special Specifications | Working environment temperature:-15C to 50C; Storage temperature:-14C to 70C; Humidity:95%; Packaging:IP54; Impact & Vibration resistance: 25G/2G; Weigh:<500g; Size:172mm x 80mm x 162mm; Reporting software. |
Accessories:
Battery, Charger, 2G memory card, card reader, Lens cap, CD software(can't connect with PC, just for analysing) and PDF manual
