Home > Products > Mining & Cement Equipment and Parts > 5" Quarry Rock Down The Hole Hammer
5" Quarry Rock Down The Hole Hammer
- Shanghai Port Ningbo Port
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | Hi-sea | |
| Model Number | HS130 | Type | Other, DTH Hammer | |
| Machine Type | Drilling Equipment | Certification | API | |
| Material | Carbide | Processing Type | Forging | |
| Use | Other, Quarry Drilling, Coal Drilling |
Product Description
Down The Hole Hammer:
5" Quarry Rock Down The Hole Hammer
Six Points:
1. Deliver maximum energy to drilling bit, fast drilling speed and low air consumption
2. Smooth performance and long service life
3. Low problem rate and easy to maintenance
4. Easy to depart bit from hammer
5. Interchangeable with drill pipe and drill bit
6. The advanced technology, valveless air distribution
Various Down The Hole Hammers Specification:
Model | Outside diameter | Length | Weight | Working pressure | Impact frequency | Air consmption | Thread connection | Match bit | ||
mm | inch | mm | kg | Mpa | hz | m3/min | mm | |||
HS80 | 81 | 3 | 869 | 23 | 0.7-1.4 | 16-18 | 6-10 | T48*10 | 90-110 | |
HS100 | 99 | 4 | 1046 | 42 | 1.0-2.5 | 27 (at 1.7Mpa) | 6-15 | API(2 3/8)" REG | 110-135 | |
HS100A | 99 | 4 | 985 | 38 | 1.0-2.5 | 30 (at 1.7Mpa) | 6-14 | API(2 3/8)" REG | 110-135 | |
HS130 | 125 | 5 | 1226 | 75 | 1.0-2.5 | 25 (at 1.7Mpa) | 9-23 | API(2 3/8)" REG | 135-155 | |
HS130 | 125 | 5 | 1226 | 76 | 1.0-2.5 | 25 (at 1.7Mpa) | 9-23 | API(2 3/8)" IF | 135-155 | |
HS130 | 125 | 5 | 1226 | 78 | 1.0-2.5 | 25 (at 1.7Mpa) | 9-23 | API(3 1/2)" REG | 135-155 | |
HS130A | 126 | 5 | 1105 | 67 | 1.0-2.5 | 28 (at 1.7Mpa) | 7-19 | API(2 3/8)" REG | 135-155 | |
HS130A1 | 126 | 5 | 1105 | 68 | 1.0-2.5 | 28 (at 1.7Mpa) | 7-19 | API(2 3/8)" IF | 135-155 | |
HS130A2 | 126 | 5 | 1120 | 70 | 1.0-2.5 | 28 (at 1.7Mpa) | 7-19 | API(3 1/2)" REG | 135-155 | |
HS150G | 136 | 6 | 1392 | 105 | 1.0-2.5 | 23 (at 1.7Mpa) | 10-28 | API(3 1/2" REG | 152-203 | |
HS150 | 136 | 6 | 1376 | 105 | 1.0-2.5 | 23 (at 1.7Mpa) | 10-28 | API(2 3/8)" IF | 152-203 | |
HS150A | 143 | 6 | 1238 | 100 | 1.0-2.5 | 25 (at 1.7Mpa) | 9-26 | API(3 1/2)" REG | 152-203 | |
HS180 | 181 | 8 | 1545 | 205 | 1.0-2.5 | 20 (at 1.7Mpa) | 15-34 | API(4 1/2)" REG | 195 | |
Forging Down The Hole Hammer with Drill Bit:
Detailed:
Detailed (Different Types):
Every Part:
Down The Hole Hammer, Drill Bit, Drill Rod:
