Home > Products > NDT Instruments > NEW UM-4 A-Scan Snapshot Ultrasonic Wall Thickness Meter tester gauge Fast shipping of EMS DHL Fedex

NEW UM-4 A-Scan Snapshot Ultrasonic Wall Thickness Meter tester gauge Fast shipping of EMS DHL Fedex

FOB Price

US$ 600 - 920 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsT/T D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Graigar
Model Number	UM-4, UM-4

Product Description

Instruments

NEW UM-4 A-Scan Snapshot Ultrasonic Wall Thickness Meter tester gauge Fast shipping of EMS DHL Fedex

UM-4 first provides A snapshot scanning waveform display function in the same product class.Ultrasonic is no longer an abstract concepts.Users can see directly on the screen of ultrasonic signal,to verify the thickness reading is correct, analyze the cause of the problem and help the user to find the solution to the problem.

The only real 0.01 mm resolution of ultrasonicthickness meter in the same product class.

Ultrasonic thickness gauge display resolution is usually 0.01 mm, but it's hard for the real resolution up to 0.01 mm.Ordinary Timing counter within the thickness gauge is generally below 30 MHZ,With the breakthrough full digital technology and special algorithm, The true resolution of UM-4 can reach 0.01 mm, Lots of experiments prove that it's easy for UM-4 to distinguish that thickness is only 0.01mm of two blocks.

Adopted the zero measurement technology

Based on full digital technology,with the zero measurement technology,the measured value will not be affected by echo intensity,material attenuation coefficient,the gain and the height of the gate,so the result was of high stability and reliability.

Instrument Specifications
Display Type	2.4" color OLED, 320 X 240 pixels, contrast 10,000:1
Operating Principle	Pulse echo with dual element transducers
Measuring Range	0.60mm to 508mm(0.025" to 20.00"), depending on material, probe and surface condition
Measuring Resolution	Selectable 0.01mm, 0.1mm (selectable 0.001", 0.01")
Units	Inch or Millimeter
Gain	Low, Medium or High for varying test conditions
Display Mode	Normal, Minimum / Maximum capture, DIFF/RR%
V-Path Correction	Automatic
Update Rate	Selectable 4Hz, 8Hz, 16Hz
Material Velocity Range	500 to 9999m/s (0.0197 to 0.3937in/us)
Languages	Selectable Chinese, English, Japanese
Alarm Settings	Minimum and Maximum alarms. Range of 0.25 mm to 508 mm (0.010" to 20.00").Dynamic waveform color change on alarm
Power Requirements	2 AA size batteries
Operating Time	Approximately 40 hours
Instrument Shut-off	Selectable ALWAYS ON or AUTO OFF after 5, 10, 20 minutes of inactivity
Operating Temperature	-10°C to +50°C (+10°F to +120°F)
Size	153mm X 76mm X 37mm(H X W X D)
Weight	280g including batteries
