Portable digital ultrasonic flowmeter TDS-100P/ flow meter/water meter with the function of print

Specifications

Portable digital ultrasonic flowmeter TDS-100P/ flow meter/water meter with the function of print

Product features: 1, high precision measurement: linearity is better than 0.5%, the repeatability accuracy better than 0.2%, measurement precision is better than that of plus or minus 1% 2, large measuring range: choose different types of sensors, which can realize caliber DN15 ~ DN6000mm pipe flow measurement 3, support Chinese and English menu: different versions of the flowmeter, can support Chinese or English menu, convenient and quick 4, easy installation, compact structure, strong, adopting international advanced die-casting aluminum shell. 5, strong anti-jamming capability, adopts double balanced differential signal transmitting and receiving circuit, effectively resist inverter, television tower, strong interference sources, such as high tension line 6, measurement data on-site printing;

Technical parameters: Host: backlit LCD can display instantaneous flow rate and flow velocity at the same time, accumulated flow rate and time, heat and other data Signal output, current output: 4 ~ 20 ma Data interface: RS - 232 or RS - 485 Automatic memory before 64, 64 month before, the first five years of accumulated flow, automatic memory before 64 calls and interruption time and flow, automatic record 64 days before the working state of the flow meter is normal Cable length: ultrasonic principle of special cable as short as possible, in order to reduce interference. Can also be extended to 300 meters should be user requirements. Pipe: steel, stainless steel, cast iron, cement pipe, PVC, aluminum, glass fiber reinforced plastic, hard metal plastic, such as quality of pipeline, the lining is allowed Measuring medium: water, sea water, industrial wastewater, acid alkali, various oil can sound conduction liquid, etc Power supply: AC220V or DC24V or DC12V built-in rechargeable batteries work over 12 hours Power: 2 w

High precision measurement Linearity is better than 0.5%, the repeatability accuracy better than 0.2%, measurement precision is better than that of plus or minus 1% Non-contact measurement Ultrasonic flowmeter with magnetic sensor adsorbed on the outer wall of pipeline, can complete the flow measurement Wide measuring range Choose different types of sensors, which can realize caliber DN15 ~ DN6000mm pipe flow measurement Support in both Chinese and English menu Different versions of the flowmeter, can support Chinese or English menu, convenient and quick Charging power supply Built-in high-capacity nickel-metal hydride rechargeable batteries, can support the flowmeter work continuously more than 20 hours The built-in printer Can achieve instant screen printing, can also be timing print set up to more than 20 items of measurement result in advance. Built-in data recorder In advance can be set up to more than 20 items of measurement results will be uploaded to the computer or network communication
