Home > Products > Toughened glass insulator( cap and pin type ) > Sep. New Listing / LXY-70 Glass Insulator
Sep. New Listing / LXY-70 Glass Insulator
- Shanghai guangzhou shenzhen
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Jiangxi, China | Brand Name | Beste | |
| Model Number | LXP-70 | Type | Insulator | |
| Material | Other, glass | Application | High Voltage | |
| Rated Voltage | 110kV | Tensile Strength | 70kN |
Product Description
IEC standard insulators | U70B/127 | U70B/146 | U70B/140 |
Mininum mechanicatl failing load | 70kN | 70kN | 70kN |
H spacing H | 127mm | 146mm | 140mm |
D Diameter D | 255mm | 255mm | 255mm |
L Creepage L | 320mm | 320mm | 320mm |
Ball and socket soupling | 16 | 16 | 16 |
Stainless steel security clip | W | W | W |
Powey frequency withstand voltage for unit | 150kV/40kV | 150kV/40kV | 150kV/40kV |
Lighting impulse withstand voltage for unit | 420kV/100kV | 420kV/100kV | 420kV/100kV |
Power frequency puncture voltage | 130kV | 130kV | 130kV |
Electric iron visual test | 18kV/22kV | 18kV/22kV | 18kV/22kV |
Impulse puncture voltage | 2.8p.u | 2.8p.u | 2.8p.u |
Power frequency electric arc voltage |
0.12s/20kA |
0.12s/20kA |
0.12s/20kA |
Net weight per unit | 3.5Kg | 3.6Kg | 3.6Kg |
Contact Us
- Pingxiang Best Insulator Group Co., Ltd.
- Contact nameZhiWei Luo Chat Now
- Phone86-0799-6378286, 6378186
- AddressFutian Industrial Park, , Pingxiang, Jiangxi
