Home > Products > Line Post Insulators For High Voltage > Vertial Type Line Post Insulators
Vertial Type Line Post Insulators
US$ 16.8 - 17
/ Piece
2000 Pieces(Min. Order)
- Shanghai
- T/T L/C D/P D/A Money Gram
You May Like
Product Details
| Place of Origin | Jiangxi, China | Brand Name | Beste | |
| Model Number | 57-5S&5L | Type | High Frequency Ceramics | |
| Material | Other, porcelain |
Product Description
57-5 line post insulator technical data
Creepage Distance | 1143mm |
Dry Arcing Distance | 438mm |
Cantilever Strength | 12.5kN |
Lower Frequency Dry Flashover | 175kV |
Lower Frequency Wet Flashover | 150kV |
Critical Impulse Flashover,Pos | 290kV |
Critical Impulse Flashover Neg | 380kV |
Test Voltage to ground | 44kV |
Maximum RIV at 1000 KHZ(uV)1000KHZ | 200 |
Net Weight Each Approx | 18kg |
Number in Standard Package | 2 |
Product photos
Other series product photos
Contact Us
- Pingxiang Best Insulator Group Co., Ltd.
- Contact nameZhiWei Luo Chat Now
- Phone86-0799-6378286, 6378186
- AddressFutian Industrial Park, , Pingxiang, Jiangxi
