Carbon fiber cng cylinder/Air cylinder/300bar composite cylinder Standard EN12245
- Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
Standard EN12245 Air cylinder/4500 psig tank Made in China with 3L/6.8L/9L for SCBA
-
Standard EN12245 Air cylinder/Air tank Made in China with 3L/6.8L/9L for SCBA
-
Standard EN12245 aluminium composite tank Made in China with 3L/6.8L/9L for SCBA
-
standard EN12245 Petroleum Air cylinder/carbon cylinder 300bar high quantity
-
Exploration Air cylinder/carbon cylinder 300bar standard EN12245 with high quantity
-
Stainless steel gas cylinder for SCBA
Product Details
| Place of Origin | Shanghai, China | Brand Name | AS | |
| Model Number | AS |
Product Description
Carbon fiber cylinders
Brief Introduction:
AS SCBA and life support cylinders feature aluminum alloy liner with thin wall and full-wrapped composite material exterior with carbon fiber and glass fiber with are suitable for SCBA, oxygen respirator, fire extinguisher, medical aid and emergency, as well as for use in automobile, space industry, etc.
Detailed Product Description:
Type | 3/30 | 6.8/30 | 9/30 | ||
Filling gas | AIR | ||||
Usage time | ≥30mins(30L/min during breathing) | ≥60mins(30L/min during breathing) | ≥90mins(30L/min during breathing) | ||
Total weight | 2.1KG | 3.9KG | 5.3KG | ||
Material | Carbon fiber composite material (Full-wrapped Carbon fiber) | ||||
Water Capacity | 3L | 6.8L | 9L | ||
Service pressure | 30M Pa | ||||
Test pressure | 45M Pa | ||||
Outer Diameter | 114mm | 157mm | 175mm | ||
Length | 446mm | 530mm | 560mm | ||
Thread size | M18*1.5mm | ||||
Characteristics & Features:
AS SCBA and life support cylinders offer the following advantages:
1. Light weight: Up to 30 percent lighter than comparable steel cylinders;
2. Outer layer with full-wrapped superior glass fiber features creep resistance, shock resistance and corrosion resistance, etc.;
3. High pressure resistance;
4. Leakage first before explosion;
5. No splashing fragment in explosion
