Home > Products > Mortar mixer > Henan Better Plastering Mixer
Henan Better Plastering Mixer
- Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | dry mortar production line | |
| Production Capacity | 10m3/h | Place of Origin | Henan, China | |
| Brand Name | Better Plastering mixer | Model Number | GF | |
| Voltage | 380v | Power(W) | 150kw-250kw | |
| Dimension(L*W*H) | 10m*6m*8m | Weight | 6000kg | |
| Features | high quality, cheap price | Certification | ISO9001 | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Better Plastering mixer advantages
1.special process let the products have the resistance to shrinkage,crack resistance,heat preservation,moisture proof.
2.Have a material level sensor and the dust collecting device,can be automatically controlled feed rate and prevent the dust in the sky.
3.PLC and PC control mode can perfect processing ingredients,weighing and mixing the whole production process of automatic control.
4.Have a system to expand client's database and network function.
5.Easy operation and maintanance.
Better Plastering mixer parameter
| Parameters Name | Production Line Model And Parameter | |||
| Name | GF5000 | GF4500 | GF3000 | GF2000 |
| Theory Productivity(t/h) | 80-85 | 55-60 | 35-40 | 20-25 |
| Productivity (10000t/year) | 40 | 30 | 20 | 10 |
| Mixer Model | DH5000 | DH4500 | DH3000 | DH2000 |
| Mixer Volume | 5 | 4.5 | 3 | 2 |
| Mixer Load Factor | 70% | 70% | 70% | 70% |
| Mixer Power | 90 | 75 | 55 | 45 |
| Dryer Model | RD3275 | RD3270 | RD3265 | RD2560 |
| Dryer Capacity(t/h) | 70-80 | 50-60 | 45-50 | 30-35 |
| Dryer Power(KW) | 4*11 | 4*7.5 | 4*7.5 | 2*11 |
| Powder Material Silo Configuration(m3) | 3*120 | 3*80 | 3*80 | 3*50 |
| Sand Silo Configuration(m3) | 3*140 | 3*140 | 3*140 | 3*80 |
| Additive Silo Configuration(m3) | 2*1.5 | 2*1.5 | 2*1.5 | 2*1.5 |
| Sand Measuring Scales Volume(m3) | 3 | 2 | 1.2 | 0.6 |
| Sand Measuring Scales Accuracy(%) | ≤±1.5 | ≤±1.5 | ≤±1.5 | ≤±1.5 |
| Powder Material Measuring Scale Volume(m3) | 1.5 | 1 | 0.8 | 0.4 |
| Powder Material Measuring Scale Accuracy(%) | ≤±1 | ≤±1 | ≤±1 | ≤±1 |
| Additive Measuring Scale Volume(m3) | 0.6 | 0.6 | 0.5 | 0.5 |
| Additive Measuring Scale Accuracy(kg) | ±0.05 | ±0.05 | ±0.05 | ±0.05 |
| Production Line Overall Dimension(L*W*H)(m) | 22*15*28 | 22*15*28 | 22*15*28 | 22*15*28 |
| Installed Power(KW) | ≈420 | ≈380 | ≈350 | ≈320 |
IF ANY QUESTIONS,BETTER CALL BETTER!!!
1.Pre-sale service:
We will give you suggestive productive technical processing in the prophase plan and manufacturer equipment based on your special demand.
2.Sale service:
If needed, our advanced technicians will be sent your jobsite to guild operation and installation. finish your job together.
3.After-sale service:
In order to keep our cooperating relationship on, we will send technicians to visit to you, making sure the products works normally.
4.We provide one-year warranty to make products works normally. we also offer lifelong service and wearable parts for you.(In addition to artificial damage)
1.Where do your customers come from?
Our clients includes those Fortune 500 companies like China Water Agency, China Sinohydro Corporation, Henan Construction Engineering Co, China South-to-north Water Project and lots of cities and towns housing construction companies.
2.What about your International Market?
We have established overseas project in more than 19 countries and regions, just like Outer Mongolia, Russian, Philippine,Macedonia,Tanzania, Cyprus etc and won overseas customer’s trust and good reputation.
3.What is the payment term?
T/T, L/C, Western Union, Paypal, cash
4.How to transport and install this production line equipment?
Containers or as your order.Use crane to load into the container,wire cable fastened inside the container,cork wood to forbid collision.
5.What are your main products?
(1)Concrete mixer plant,concrete mixer machine,JZC/JDC/JZM portable concrete mixer.
(2)Dry mortar mixer plant,dry mortar mixer machine,dry mortar mixer auxiliary equipment.
(3)Conrete batch plant,cement silo,sand dryer,sieving machine,bar straighting machine,control computer etc.
Containers or as your order
1.Use crane to load into the container
2.Wire cable fastened inside the container
3.Cork wood to forbid collision
