Network IP based alarm system with LCD display, work with CMS, can connect with wired& wireless sensors

Specifications

Network IP based alarm system with LCD display, work with CMS, can connect with wired& wireless sensors

1.Function discription:

N-11 is an network-based alarm, the alarm message can be transmitted to the alarm platform via internet cable, through the configuration tool on the computer and to complete the following functions: learn and remove the accessories, export operation log information, turn on or off time arm/disarm,change time for timing, set the current time,siren sounding time, etc. You can also arm or disarm the system remotely through the web , and check time arm and disarm or relevant information, report arm and disarm the state every 20 minutes to the platform.

2.PC System requirements:

•  Operating System: Microsoft Windows 98 SE, ME, 2000, XP
•  CPU: 1.6G over the configuration
•  Browser: Internet Explorer 5.x or above

3-1 The interface functions are shown below:

1.Internet cable interface

2.External power adapter interface(connnect 9V500MA power adapter)

3.External wired siren interface

4.Wired zone common port

5.Fourth wired zone

6.Third wired zone

7.Second wired zone

8.Built-in battery switch

9.Wireless antenna

10.built-in battery switch connecting wires(after system installed,please use a wire to connect COM with 1,see picture above,otherwise the panel can not work if power failer and can not upload power failer message to the monitoring platform)
