G45 PP/PS led bulb blow molding machine
- shanghai port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
5ml-60ml eye dropper blow molding machine
-
HDPE tablet bottle blow molding machine
-
china cheapest supplier for 5ml-60ml eye dropper plastic mold making
-
manufactures plastic dropper bottle mold for 10ml ldpe plastic eye dropper bottle
-
plastic mold manufacture for hdpe blow mold
-
1liter hdpe plastic pesticide bottle blow mold
Product Details
| Place of Origin | Jiangsu, China | Brand Name | FD | |
| Model Number | led bulb blow molding machine | Shaping Mode | Blowing Mould | |
| Product Material | Plastic | Product | Other, led bulb blow molding machine |
Product Description
»Operating Principle
Station A:Preform injection
The bottle neck will be molded accurately after injecting the material into the cavity,After proper control,the mold open and mandrils to...along with the cavity.
Station B:Blow molding
Blowing action was done at this part,molding would be complete after cooling.(bottle shape decides by the mold cavity).The air came out from the mandrils huffs the cavity,make the cavity cling to the mold.Then mold open and the mandrils turn to...along with bottles.
Station C:Stripper
The bottle automatically will be ejected from the mandrils at this position and then to be packed.The three actions of injection/blowing/ejection working at the same time,which makes the machine of high efficiency and low waste with bottles.
»Reference cavity numbers on each model machine
| Approx Volume(ml) | Max.body diameter(mm) | Mini.neck diameter(mm) | Max.height(mm) | Mini.weight(g) | Max.cavity on FD30 | Max.cavity on FD45 | Max.cavity on FD60 |
| 10 | 24 | 7 | 60 | 2 | 9 | 13 | 18 |
| 30 | 30 | 8 | 75 | 4 | 8 | 11 | 16 |
| 60 | 45 | 14 | 90 | 7 | 6 | 8 | 11 |
| 80 | 50 | 15 | 100 | 9 | 5 | 7 | 10 |
| 120 | 60 | 18 | 120 | 14 | 4 | 6 | 8 |
| 250 | 65 | 20 | 150 | 25 | 3 | 4 | 6 |
| 500 | 85 | 25 | 220 | 35 | 2 | 3 | 4 |
| 1000 | 95 | 40 | 240 | 60 | 1 | 2 | 3 |
»Product Features
Excellent machanical strength.impact-resisting,and non-cracking.
Bottle mouth and screw thread are of precise measurement,enable 100% close matching with the bottle cap.
The weight of the product can be pre-setted.
The measurement and thickness of the product can meet the requirement of the design without any deviation.
The surface of the bottle mouth and body is bright and smoonthness.
No defleshing and trimming save the material cost.There is no joint seam at the bottom,and strength is improved accordingly.
The joint seam on the bottle body is smooth.
»Packaging & Shipping
machine packed with film and wooden pallet
mold packed by sea worthy wooden cases.
