Guanya Water Chiller Unit Shell and Tube Type Evaporator GYD-10

FOB Price

US$ 200 - 7,000 / Piece

1 Piece(Min. Order)

Port Shekou
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Guanya
Model Number	GYD-10	Type	Condenser
Application	Refrigeration Parts	Certification	CE

Product Description

Guanya Water Chiller Unit Shell and Tube Type Evaporator GYD-10

Shell and tube type evaporator features simple structure, outstanding heat transfer capacity and easy maintenance. It is specifically designed for air conditioning system, cooling system, heat pump and processing system, widely used in refrigerating machinery and power plant.

Features

l outstanding heat transfer capacity - ranges from 11340kal/h to 1134000kcal/h

l precise CNC processing and manufacturing – technical index reaches international advanced level

l side cover design – ensures easy maintenance

l male screw copper tube and hermetic structure – improve the heat transfer performance

l compatibility with HCFC, HFC and other refrigerants

Parameters

Parameters of evaporator(Double Circuit)
itemModel No	Unit	GYD-10	GYD-15	GYD-20	GYD-25	GYD-30	GYD-40	GYD-50	GYD-60	GYD-80	GYD-100	GYD-120	GYD-160
Chilling capacity	RT	5*2	7.5*2	10*2	12.5*2	15*2	20*2	25*2	30*2	40*2	50*2	60*2	80*2
Dimensions	Amm	1180	1230	1600	1600	1600	2000	2000	2350	2350	2600	2600	3000
	Bmm	1100	1150	1500	1500	1500	1900	1900	2250	2250	2500	2500	2900
	C	270	270	270	320	320	370	370	370	410	410	410	460
	D	8″	8″	8″	10″	10″	12″	12″	12″	14″	14″	12″	16″
	Emm	80	80	80	100	120	150	150	200	200	200	200	250
Pipe Diameter	Refrigerate entrance cu	5/8″	5/8″	7/8″	7/8″	7/8″	1-1/8″	1-3/8″	1-3/8″	1-3/8″	1-5/8″	1-5/8″	2-1/8″
	Refrigerate exit cu	7/8″	7/8″	1-1/8″	1-1/8″	1-1/8″	1-3/8″	2-1/2″	2-1/2″	2-3/4″	2-5/8″	3-1/8″	3-1/8″
	drain outlet	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″	3/4″
	coolwater outlet B	1-1/2″	2″	2″	2-1/2″	2-1/2″	3″	3″	4″	4″	4″	5″	5″
t hickness of tube body	mm	4	4	4	4	5	5	5	5	6	6	6	6
thickness of tube plate	mm	24	24	24	24	24	24	24	24	24	24	24	24
diameter of cooper pipe	Cu							5/8″
heat radiating area	m2	1.49	2.48	3.96	4.95	5.95	7.43	9.90	19.8	29.7	34.65	32.66	32.66
water flow	m3	1.50	2.50	4.00	5.00	6.00	7.50	10.00	20.00	25.00	30.00	35.00	35.00
weight	kg	16	27	43	53	64	80	107	213	267	320	373	373
