Customized Power Distribution Transformer Substation

CUSTOMIZED POWER DISTRIBUTION TRANSFORMER  SUBSTATION

ABOUT SHOUGUANG JUNENG ELECTRIC CO., LTD

PRODUCT FEATURES

1. BXW series pre-loaded Europe box transformer substation consists of HV switchgear, power transformer and LV switchgear.

2.it has the features of samll space, less investment, easy assembly, good-looking apperance and weather resistance.

3.the transformer is a type of oil-immersed or epoxy resin dry transformer with low loss, low tempreture rise, low noise, full-sealing and free maintenance.

4. high voltage unit is composed of incoming, outgoing and meter cabinet.

    low voltage unit consists of meter cabinet, general breaker line cabinet, LV feeder cabinet, capacitor       compensation cabinet.

5.service condition

1) altitude: less than 2500m

2) ambient temperature:-50 ℃ -+40 ℃

3) relative humidity: daily average value up to 95%; monthly average value up to 90%

4) seismic intensity 8 degree: horizontal acceleration no more than 0.3g

5) service occasion without regular vigorous vibration

6)ambient environment is not polluted by corrosive or inflammable gas.

7)installation inclination is less than 3 degree.

8) wind speed is equal or less than 34m/s

6.payment terms: T/T with 30% deposit  or L/C

7.packing detail: wooden case or at the requirement of customers

8.delivery time: usually within 30 days after the deposit

What we can do better

• Quality Assurance--From the very beginning, JUNENG ensures quality in every step to achieve the best quality.
• Experience Sharing--With over 10 years’ experience in power industry, JUNENG brings you an optimized solution.
• Quick Response--In response to your needs without delay, JUNENG knows the value of your time.

Technical Parameters

rated voltage: HV 12kv  LV 0.4kv

transformer rated capacity: 50-1600kva

rated current: HV 630A  LV 100-2500A

rated frequency: 50Hz

rated short-time withstand current : HV: 16kA/2(4)s   20kA/2(4)s LV: 250-315kVA:15kA  400-800kVA:30kA

rated noise level: oil immersed transformer  less than;  50db dry transformer less than 55db

MORE DETAILS, PLS CONTACT US.
