230 watt mono solar pv module price for industrial panel

FOB Price

USD $0.75 - $0.95 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

230w mono pv module

230W Monocrystalline Solar Panel with Competitive Price
TUV,CE,MCS,UL,CEC,IEC61215and IEC61730,ISO9001,ISO 14001VDE certificate

1.Type:156*156mm mono solar cells
2.Cert:TUV,UL,CE,RoHS,ISO9001,ISO14001
3.Glass:High transmissivity low iron toughened glass

54pcs 156×156mm mono-crystalline silicon cell

Electrical Characteristics

Maximum Power(Pmax) W 230W

Open Circuit Voltage(Voc) V 37.20V

Short Circuit Current(Isc) A 8.26A

Maximum Power Voltage(Vmp) V 29.60V

Maximum Power Current(Imp) A 7.61A

Max.ststem.Operation.Voltage V 1000

Diodes 3 by pass

Dimension mm 1747*986*50

Weight kg 16.8

Operate Temp.scope °C -40/+85

Resistances 227g steel ball fall down from 1m height and 60m/s wind

25 years 80% of Power output
