Yidaneng Power Yangdong 10kw Biogas Generator Genset

FOB Price

US$ 2,000 - 6,000 / Set

1 Set(Min. Order)

Port Qingdao China
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	YIDANENG
Model Number	YDN-10GFZ	Output Type	AC Three Phase
Speed	1500/1800rpm	Frequency	50/60HZ
Rated Power	10kw biogas generator	Rated Voltage	230/400V
Rated Current	18A

Product Description

Yidaneng Power Yangdong10kw biogas generator genset

1.Gas generator set chooses the domestic famous brand engine as the dynamic force.

2.These gas generator have wide range of power capacity, good starting performance and excellent dynamic performance.

3.With the importing of technology of Yangdong Company .The engine feature s in low fuel consumption rate, good dynamic performance, safety and reliable.

4.Yidaneng Gas generator set is widely used as major or back up power supply in fieldwork, high building, supermarket, factory, ore yard, oil field, high road, harbor countryside and so on.

Product Description

Generator	Genset Model	YDNGFZ-10
	Rated Frequency	50HZ
	Power Factor	0.8
	Rated Voltage	400/230V
	Rated Power (KW/KVA)	10/12.5
	Standby Power (KW/KVA)	11/13.75
	Rated current (A)	18
	Phase/Wire	3 Phase, 4 Wire
	Overall Size (mm)	1650×750×1150
	Weight (kg)	470
Biogas Engine	Model	YD480
	Brand	Yangdong, China
	Type	4-stroke, wet cylinder liner
	Rated Power (kw)	14
	No.of Cylinder	4.L
	Bore×Stroke (mm)	80×90
	Biogas Consumption (m3/kw.h)	0.65
	Oil Consumption (g/kw.h)	2
	Cooling Type	Closed water cooling
	Speed Governing Mode	ESC
	Starting Mode	Electric
Alternator	Model	164B
	Rated Power (KW/KVA)	10/12.5
	Power Efficiency	96.60%
	Voltage Regulation	≤±1.5
	Excitation Type	Brushless
	Insulation Class	H
Control System	Model	Smartgen6110
	Working Voltage	DC8.0V to DC35.0V, continuous
	Overall Dimensions	197 mm x 152 mm x 47mm
	Panel Cutout	186mm x 141mm
	Working Condition	Temperature: (-25~70)ºC; Humidity: (20~90)%
	Weight	0.56kg

Product Overviews

*Gas Generator Picture's Show :

Silent type biogas generator:

Certifications

Exihibition:

Supply Service

Supply Service:


1.	Pre-Sale Services High performance products with installation, design or material and quick repairmant; Expert engineers offer technical consultation and assort guidance to our customers, such as questions and offer technical help during any time.
2.	Quality of Service Professional technical adviser; Once we get inform from our customer, we send technical engineers to scene and help to installation and debug the generator, and cooperate with customer to check and accept the generator. The products with most appropriate design and optimization.
3.	After-Sales Service Establish customer service files for end users, provides operations, technical guidance, tracking service, regular visits, life-long maintenance. Design machine room and the offer follow-up service and regular inspection.
4.	Free quick-wear parts offer spare parts and technical help at any time.

Packaging & Shipping

*Plywood Case &Stretch Film Packing
