Ultra Light and Portable Axle Weighing Scales

Specifications

Ultra light and portable axel weighing scale

Description

ZH180F is made of aluminum alloy, and it is ultra thin, light and portable. Compared with other products, the foldable plastic slope greatly improve measuring dynamic accuracy.

One ZH180F can statically or dynamically measure wheel weight, so double can be parallelly connected to measure axle weight. And the instrument, which is connected, can calculate the vehicle weight.

.

Features:

It is made of aluminum alloy, and it is ultra thin, light and portable.

Compared with other products, the foldable plastic slope greatly improve measuring dynamic accuracy.

The net weight is 38kg, and the length of weight-bridge is changed to 800mm from 700mm.

One ZH180F can statically or dynamically measure wheel weight, so double can be parallelly connected to measure axle weight. And the instrument, which is connected, can calculate the vehicle weight.

Parameters

Rated load: 20t  portable axel weighing scales

Rated output: 0.9±0.1mv/v

Repeatability: 0.05%FS

Error on transverse: 0.1%FS

Zero balance: ≤1%FS  portable axel weighing scales

Static comprehensive error: 0.1~0.5%FS

Dynamic comprehensive error:

1.0%FS(1~5km/h) 3~5%FS(5~10km/h)

Non-linearity: 0.2%FS  portable axel weighing scales

Use temp.range: -30~80°C

Compensated temp.range: -10~50°C

Temp.effect on span: 0.03%FS/10°C

Temp.effect on zero: 0.05%FS/10°C

Output resistance: 1000±3Ω

Defend grade :IP 66/IP 68

Ultimage overload: 150%FS

Recommended voltage: 10V

Excitation voltage: 9~15V

Net weight: 38kg

Max load of 1 /4 weigh bridge: 8t

Full load: 20t

Dimension of the surface:

882×500mm

Insulation resistance: ≥

5000MΩ(100VDC)

Remark: Four-core shielded

cable is attached: φ5.8×10m

(The cable length can be changed according to customer's request)
