Acceleration sensor speed transducer/speed transmitter

Specifications

Acceleration sensor/speed transducer/speed transmitter

Description

 AT3000 acceleration sensor speed transducer speed transmitter is our latest developed micro-transmitter with a small and exquisite appearance.  The integrated chassis vibration transmitter consists of piezoelectric sensing element with measurement, conversion, integral,  amplification, transmission and other major circuits, all the indicators accord with standards of “ISO2954-1975" and "  GB13824-1992".

AT3000 installed built-in precision integral circuit to provide speed output,  based on  Piezoelectric Acceleration Transducer. Compared with magneto-electric velocity transducer. It has lots of advantages, for example, it has wider response frequency range (2HZ-4000HZ), mechanical moving parts are not easy to   damage   (working life up to 7 years), lightweight, excellent dynamic performance and so forth. AT3000 provide 4-20mA current output, wiring fault-tolerant protection, with  excellent  stability  reliability  and  strong  anti-interference ability.

Features

Durable design

Corrosiveness resistance

Good sealing

ESD protection

Reverse polarity protection

EMI/RFI Electromagnetic interference or RF shielding

Dynamic characteristics

Sensitivity:±5%, 25C

Acceleration range:80g peak value

Amplitude nonlinear:1%

Frequency response

±5%...............................................................................................3-5000Hz

±10%..............................................................................................1-9000Hz

±3dB…………………………………………………………………...0.5-14000Hz

Resonance frequency………………………………………………...30KHz

Cross sensitivity (Max)…………………………………………………5% of Axial

Temperature response: -50°C to +120°C……………………………..+/-10%

Electrical characteristics

Power supply……………………………………………………………18-30VDC

Current regulation diode……………………………………………….2-10mA

Electrical noise g:

Frequency band: 2.5Hz-25KHz……………………………………….700µg

Frequency spectrum: 10Hz ……………………………………………10µg/vhz

100Hz ………………………………………….5µg/hz

1000Hz ……………………………….……..…5µg/vhz

Output resistance (Max)……………………………………………….100

Offset output voltage………………………………………………….12VDC

Ground …………………………………………………………………internal shield

Environmental character

Temperature range………………………………………………..-50C to 120C

Vibration limited …………………………………………………..500g peak

Shock limited ……………………………………………………..5000g peak

Electromagnetic sensitivity, equivalent.g ………………………70µg/gauss

Sealed……………………………………………………………. air tightness

Base strain sensitivity …………………………………………..0.0002g/ustrain

Physical characteristics

Sensor element …………………………………………………piezoelectric ceramics shear

Weight …………………………………………………………..90g

House material …………………………………………………316L ss

Installation ……………………………………………………..1/4-28UNF

Electrical connector…………………………………………..2PIN, MIL-C-5015

Dimension

Wiring connect
