4KW Hybrid Off Grid Solar Power System (PWM Control)

Introduction

GTPL series solar system consist of the solar panels,low-frequency inverter&controller integrated ,battery ,cables and PV bracket.The solar inverter adopted the most advanced technology and the latest net-work communication technology, giving a perfect power solution for your restrict requirements. It is small, light weight and high efficiency. In inverter state, it is almost no noise. Inverter integrated with PWM technology, and its  voltage is fully sine wave output, suitable for capacitive load, inductive load and nonlinear mixed load. Also, its efficiency is 10% higher than that of other inverters; protection functions are perfect, such as overload, short circuit, battery voltage over-high or over-low, these will not cause your machine breakdown. By RS232 communication port, the inverter and power status could be monitored from the connected PC, to understand the working data, setting invreter off, monitoring the working parameters, and to expand functionality for remote network monitoring (via SNMP ADAPTER). It can meet a variety of solar power systems.

Features

²  MCU intelligent control,excellent performance;

²  Adopt power frequency transformer,pure sine wave AC output,strong capacity of different loads;

²  Excelent  design for short-circuit protection,work reliably;

²  Simple LED display shows working status clearly;

²  230VAC50HZ automatically detect the output conversion;

²  RS232 communication monitoring interface(Optional);

²  INTERNET-FAX-MODEM-ADSL line surge lighting protection;

²  Wide input AC voltage 120~280Vac;

²  Overload/ over temperature output protection;

²  Intelligent charge control can extend the life span of the battery;

²  Full-oriented protection,safe and reliable;

²  Adapt to wide range of temperature and high altitude.

NOCT				45±2℃
Voltage temperature coefficient(Voc)				-0.35%/℃
Current temperatre coefficient(Isc)				+0.055%/℃
Power temperature coefficient(Pmpp)				-0.45%/℃
Minimum power tolerance				±3%



Mechanical Data:

Solar Cell			60(6*10) Poly-crystalline 156*156mm
Front Glass			3.2mm temperd
Frame			Anodized aluminium



Electrical Data:

Module type			SL220-20P250
Nominal peak power(Wp)			250W
Nominal voltage(Vmp)			30.5V
Nominal current(Imp)			8.20A
Open-circuit voltage(Voc)			37.3V
Short-circuit current(Isc)			8.79A
Module efficiency			15.4%
Operating temperature			-40~+85℃
Maximum system voltage			1000VDC
Net weight			19.0kg
Dimension			1640*992*45mm

Structure:

Battery

Wire

• Product Name: 4 Square single PV cable
• Nominal cross section: 4mm2
• Rated Current: 55A
• Number of cores: NO 1.
• Conductor: copper structure NO / mm 56/0.30.
• Conductor Stranded Dia: 2.60mm
• Insulation minimum wall thickness: 0.5mm
• Sheath minimum wall thickness: 0.5mm
• Finished wire diameter: 6.1 ± 0.1mm
• conductor resistance (20 ℃): ≤ 5.09Ω/km
• Test voltage kV / min: 6.5 / 5 No breakdown
• Rated temperature: -40 ~ +90 ℃
• Maximum conductor temperature: +120 ℃
• Short circuit allows the reference temperature: 200 ℃ 5S
• Life:> 25 years (-40 ~ +90 ℃)
• Rated voltage: DC: 1.8kv AC U. / U: 0.6/1kv
• Working temperature ℃: -40 ~ +90
• Operating voltage AC / DC (KV): 0.6 ~ 1.0/1.8
• Weather resistance: UV
• Flame: single vertical burning (IEC60332-1)
• Sunlight resistant test: HD605/A1
• Test the finished cable Ozone: EN50396
• Smoke density: IEC61034, EN50268-2
• Halogen acid release: IEC670754-1 EN50267-2-1
• Weight: 0.2Kg / m



Installation step:









Accessories:



 Packaging: Wooden/Carton box and free accessories.
