Environment Friendly Waste Paper Pencil Making Production Line Machine

 Advantage of paper pencil making machine :

1. state support environmental protection industry

2. cost less than wooden pencils

3. performance was better than wooden pencils

4. the production process is simple

Introsuction of paper pencil making machine :

the latest generation of series of paper pencil equipment, with the most advanced level, improve and streamline the production process, automatic coating film shot machine, fully automatic coating cycle, a computer for 8 hours can pen 18000 --- 20000 volumes, provincial working hours, the volume bar effect; no pollution, no huge investment in the end, non-timber can not produce the history of pencils, wooden pencils factory investment business and the ideal equipment for changing products .

production process:

paper cutter → rolling machine →drying → cutting and polishing → shrinking machine→

eraser

Mahchine details of paper pencil production line :

1. Paper cutting machine :

This machine is to cut the 18*56cm newspapers into pieces for further processing.

Max thickness of paper: 40mm

Max length of paper: 750mm

Weight: 100kg

Dimension: 1200*1000*900

2. Pencil stick rolling machine

This machine used to roll the pieces of newspaper into pencil sticks.

When rolling, you need glue.

Productivity: 80pcs/min

Motor: 220V 1.5kw

Weight: 140kg

Dimension: 1900*450*1300mm

3. Pencil sticks drying machine :

This machine is to dry the pencil sticks.

Productivity: 4000pcs/time

Motor: 220V  2.2kw

Weight: 70kg

Dimension: 760*550*680mm

4. Pencil cutting and polishing machine all in one machine

This machine used to cut and polish the dry pencil sticks

Capacity: 100pcs/min

Motor: 220V 1.7kw

Total weight: 130kg

Dimension: 900*450*1150mm

5. Shrink packing machine :

This machine used to pack the pencils in colorful plastic papers.

Capacity: 100pcs/min

Power:220v 1.5kw

Weight: 60 kg  Dimension: 1160*430*780mm

6. Pencil heading machine

This machine is to head the eraser.

Parameters

Capacity: 30 pieces/min

Weight: 10 kg

Dimension: 600*450*1000mm

7. Packing pictures:

8. Finished product
