Home > Products > Professional Woodworking CNC Router > Gear Transmission 1325 Woodworking Machinery / Cnc Wood Carving Machine
Gear Transmission 1325 Woodworking Machinery / Cnc Wood Carving Machine
- Qingdao
- T/T
You May Like
-
Shandong Furniture Engraving CNC Machine CNC Router/Wood Making Machine for Sale
-
High Speed Wood Door Cutting Cnc Router With Auto Tool Changer
-
Wood And Metal Working CNC Router Machine
-
1325 High Quality Cnc Wood Router
-
Chencan High Quality CE FDA Certificate NK105 Control Wood CNC Router Machine
-
High Quality Multifunction 1530 Cnc Router for Making Wood Porous
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | ChenCan | |
| Model Number | CC-M1325A | Voltage | 380V | |
| Power(W) | 4.5KW | Dimension(L*W*H) | 3100mm*2000*2100mm | |
| Weight | 1300kg | Certification | CE,ISO | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Gear transmission 1325 woodworking machinery / cnc wood carving machine
1. Whole machine is welded with seamless steel structure, with aging treatment.
2. Three axes adopt Taiwan HIWIN high precision linear orbit. X and Y axes adopt rack and pinion transmission, fast working, high efficiency . Z axis adopts Germany and Taiwan ball screw,with high precision and long life time
3. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
4. Has the function of re-carving after break point and power failure. Has the function of forecasting process time.
5. Can choose updated DSP or Original Nc Studio computer control system
6. Perfect oil-inject system makes maintenance much easier.
7. Good duct-collect function and Considerate Oil plate to keep the table always clean.
8. We provide the DSP operating instruction in English, a set of cutters, software, necessary tools and accessories for free.
1 | Stroke range | X axis | 1300mm |
|
| Y axis | 2500mm |
|
| Z axis | 200mm |
2 | Process precision | ±0.05mm | |
3 | Reposition precision | ±0.025mm | |
4 | Structure | Seamless steel structure | |
5 | X,y,z structure | X, Y Helical rack and pinion, Z TBI ball screw | |
6 | Idle speed | ≥32000mm/min | |
7 | Working speed | ≥15000mm/min | |
8 | Spindle rate | 3.5kw air cooling spindle | |
9 | Spindle speed | 0-18000rpm/min | |
10 | Motor type | Leadshine servo motor | |
11 | Command code | G code, HPGL, U00, mmg, plt | |
12 | Working voltage | AC220V/380V 3phase | |
13 | Operating system | NK105 DSP control system | |
14 | Cabinet | CE standard cabinet | |
15 | Inverter | INVT | |
16 | Driver | Leadshine servo | |
17 | Collect | ER25 | |
18 | Software | Artcam | |
19 | Guide rail | HIWIN linear guide rail | |
20 | Table | Vacuum table | |
Packing and Factory:
thank you for your interest in our CNC routers, please contact me directly as following:
Robert wang
Sales manager
Skype:Robertwang417
Trademanager:cn220305274
QQ:976840302
Whatsapp/Viber:008615053485099
Wechat:15269122861
Tel:0531 88078568
Fax:0531 88078968
Mob:0086 15269122861
