Hydraulic Swing Beam Shear QC12Y-12X8000

Specifications

• The frame is entirely welded with steel plates, vibration to eliminate stress. With high strength and good rigidity.

   Hydraulic drive, return of knife beam is smooth and prompt by accumulator or nitrogen cylinder.With easy operation, reliable performance and nice appearance.

   There is indicator for adjusting the blade clearance, easily operation.

   There are safety fences in the working area to ensure the personal safety

   There are numerical display for cutting number and the length of back gauge..
• Technical data (can be provided as customers request for special model)

• Name	Data	Unit
  Max. shearing thickness	12	mm
  Max. shearing width	8000	mm
  Shearing angel	1º30
  Stroke number	5	Min-1
  Back gauge range	20-800	mm
  Main motor power	22	kw



• Feature:

  1.Hydraulic sheet plate clamping system with nylon inserts to protect metal from indentation from

  the clamp cylinders along full length of hydraulic shear machine.

  2.SNC 18 system widely used in shear machine, provides up to 1000mm travel on the screw back gauge

  allowing operator to program shear length as required.Cutting stroke counter & cutting stroke adjustment dial

  allowing shorter materials to be cut by using short stroke length,which can increase hydraulic shear machine cutting production.

  3.Simplified gap adjustment blade to allow for a variety of materials

  4.Balls inserted into hydraulic shear machine's  work table allowing plate to be moved to the shear position easily .

  5.Hydraulic shear machine top shear blade made from Inox and has two(2) cutting edges allowing minimized downtime in blade rotation.

  6.Hydraulic shear machine bottom shear blade made from Inox and has(4) cutting edges allowing minimized downtime in blade rotation.

  7.Stress of welded parts be eliminated by throw pill machine.Good rigidity and stability of hydraulic shear machine.

  8Hydraulic shear machine Shadow line lighting provide clear cutting line on the work piece and enabling scribed or marked

  plate sheet to be cut with simplicity as required.
