Individule Control Smd5050 Led Strip Ws2812b
- Shenzhen yantian
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| LED Light Source | epistar 5050 smd led | Type | Flex LED Strips | |
| Input Voltage(V) | 5v | Lamp Power | 9 | |
| Working Temperature(℃) | -30, 40 | Working Lifetime(Hour) | 50000 | |
| Lamp Body Material | PVC | Certification | CE | |
| Emitting Color | Changeable | Place of Origin | Guangdong, China | |
| Brand Name | iPixel LED | Model Number | SJ-10030-ICRGB |
Product Description
Specifications
individule control smd5050 led strip ws2812b:1.DC5V, Power 9/M
2. WS2811 chip
3.30leds/m
4.white &black PCB
individule control waterproof smd5050 led strip ws2812b(ws2811)
Features and Benefits:
1. Control IC included, supporting numerous color-change effects;
2. Pcontrol by SD controller,Arduino,DMX512,Artnet
3. Flexible PCB 5V low voltage input;
4. PCB Color: White & Black available for choose
5. Absolutely addressable ,each IC built inside RGB LED
6. 5M per roll,Customer’s size available also
Specifications:
| LED Type/brand | addressable5050 Grade A(top qualilty) |
| LED Quantity | 30/m |
| Energy Rating | A |
LED Power Consumption | 7.2w |
Input Voltage | DC5v |
Colour | Dream color(ICRGB) |
Beam angle | 140° |
Operating Temp | -40°c-40 °c |
| IC Chip | ws2811/ws2812b |
| Average life | 50,000 hours |
| color | dream color |
| Dimension | 1000mm(L)*14mm(W)*10mm(H) |
| waterproof rate | IP65 |
| Warranty | 2 years |
| Certificates | CE&RoHS |
Control System:
1. Offline control: SJ-T-1000s, SJ-8000C for off-line working, can control max 2048 Pixels, 8192 Pixels.
2. Online control: SJ-T-200K, 300K for on-line working, can control max 4096,8192 pixels.
3. Compatible with Arduino, DMX 512.
Connection:
1) Signal wire: DC+, DAT, GND
2) DC+ and GND connect to power supplier;DAT and GND connect to controller
3) Relative Controller: SPI controller support WS2801; when use DMX decorder, can connect to DMX system
4) Support online control
Product images for ws2812b led :
60led/m ws2812b led strip:
144 led/m ws2812b led strip:
Certification for 30led/m ws2812b led strip:
Service :
1.Reply your inquiry in 24 hours
2.Experienced staffs answer all your questions in fluent English
3.Customized design is available.OEM&ODM are welcomed
4.Exclusive and unique solution can be provided to our customer by our well trained and professional technicians
5.Special discount and protection of sales area provided to our distributor
Shipment:
1.Goods will be delivered within 3-5 working days after the payment received
2.We ship item via Door to Door service express or air and sea.
Waranty:
1.All products we sell are in good quality and have been tested before they are shipped out.
