591601 Pneumatic Diaphragm Pumps
- Shanghai Port Ningbo Port
- T/T Credit Card PayPal
You May Like
Product Description
Pneumatic Diaphragm Pumps
Metal range with Turboflo air valve system (formerly known as the M series)
An air operated diaphragm pump designed for simplicity in operation and maintenance.
Safe for use in explosive environments.
The Metal pump lines provides the durability, chemical resistance, abrasion resistance, and temperature range required for a variety of process and waste applications.
The standard material combination is composed of aluminum casing and neoprene diaphragm, balls and valve seat for general purpose non aggressive applications such as in oil and petroleum based fluids. Cast iron, 316 stainless steel and hastelloy casing materials are available as well.
Wilden pump features:
• Easy of operation • Intrinsically safe
• Variable speed • Ability to pass solids
• Variable pressure • Ability to run dry
• Dead head capability • No dynamic seals
| CODE | 591605 | 591601 | 591602 | |
| Model | TZ1 | TZ2 | TZ4 | |
| Standard Casing | Aluminum | |||
| Suction Lift | Dry | 14.8′ | 21′ | 22.9′ |
| Wet | 26.0′ | 29.5′ | 29.5′ | |
| Air Inlet NPT | 1/4″ | 1/4″ | 1/2″ | |
| Water | Inlet | 1/2″ | 1″ | 1-1/2″ |
| BSP/NPT | Female | |||
| Outlet | 1/2″ | 3/4″ | 1-1/4″ | |
| BSP/NPT | Female | |||
| Size | Height | 8.8″ | 11″ | 17.4″ |
| Width | 8.2″ | 10.5″ | 15.4″ | |
| Depth | 7″ | 7.3″ | 11.2″ | |
| Weight Lbs | 13 | 26 | 38 | |
