1Ton Edible Ice from Ice Cube Machine(CV1000)

Basic parameter:

Daily capacity: 1 tons per day

Refrigerant: R22 or the Eco-friendly R404a[suggested]

Standard cooling way: Water cooled type, can also design air cooling condenser

The air cooled type is all in one design, and the refrigerant have been fully charged , so it can be put in use quickly.

But for the African hot ambient temperature, to ensure the stable capacity, we suggest you have the water cooled type design.

Controlling: Germany Siemens PLC with touch screen

Ice bin: equiped, the volume is for 100kg

On the bottom of the ice bin, we designed a screw for the ice dischage, in this way, no need hand-touching the ice cubes, ensured the ice cube sanitary.

Single granule Ice cube size: 22*22*22mm, or 29*29*22mm

Material of the framework and board: FOOD STANDARD SUS304

COMPRESSOR:  BITZER  [Made in China] or BOCK [Imported from Germany]

 Koller ice cube machine parameter

Water cooled design dimension:1700*1230*1970mm / Air cooled design dimension:1800*1650*1750mm

 Ice making grids*4 pieces

Ice discharger outlet, controlled by the pedal switch

Ice making water pump

Low and high Pressure Guage

Low pressure side solenoid valve

High pressure side solenoid valve

If you choose water cooled type, the Cooling tower will be provided by us, then it is a completed set.

 So dear friend, can 1 tons daily capacity meet your needs?

For more specification, please feel free to leave your inquiry to us, we will reply with 1 hour.
