High Quality 8 Ton Knucle Boom Truck Mounted Crane for Sale,SQ160ZB3

FOB Price

US$ 19,280 - 19,800 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Construction Industry
Rated Lifting Moment	160 Kn.m	Max. Lifting Load	8 ton at 2 m
Max. Lifting Height	11.3m	Span	2330-5230mm
Place of Origin	Hubei, China	Brand Name	HBQZ
Model Number	SQ160ZB3	Certification	ISO9001:2008 TS16949
Warranty	1year	After-sales Service Provided	Engineers available to service machinery overseas

THE PEFORMANCE ON CRANE MODEL No. SQ160ZB3

Model #	SQ160ZB3 /knuckle crane 8 ton at 2 m
Max Lifting Moment	160 Kn.m
Max Lifting Capacity	8000/2.0
	3600/4.23
	2480/5.94
	1700/7.58
Max Lifting Height	11.3 m
Max Working Radius	9.6 m
Hydraulic extension boom No.s	3 stages
Rotation Angle	360º continuous
Rated Working Pressure	28 Mpa
Oil Tank Capacity	120L
Related Oil Flow	60 L/min
Outrigger Span	2330-5630mm
Outrigger	4 ,Extension, Hydraulic operating.
Crane Weight	3500kg
Installation Space	1400mm
Swing Type	Planetary gear reduction
Safety Device	Load Indicator,Hydraulic Safety Valve,Counter Balance Valve,Automatic Swing Brake,Hook Safety Device
Options	ch,Aux.Boom,Remote control
Material	HG785
