Home > Products > Sucker Rod Pumps > Tubing pump plunger used pump for oil extraction
Tubing pump plunger used pump for oil extraction
- 10000 Set / Sets per Month
- China port
- T/T
You May Like
-
High quality API 11AX Tubing pump for Pumping unit with competitive price
-
Anti-corrosion and wear resisting property API tubing pump
-
API 11AX Oilfield tubing pump for oil production
-
High quality API 11AX oil well pump with competitive price
-
High quality API 11AX Tubling Pumping with competitive price
-
Best quality API 11AX tubing pump unit with competitive price
Product Details
| Place of Origin | Henan, China | Brand Name | ZS | |
| Model Number | ZS-TPP | Theory | Reciprocating Pump | |
| Structure | Piston Pump | Usage | Oil | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Other | Pressure | High Pressure | |
| Application | Other |
Product Description
Tubing pump plunger used pump for oil extraction
Specifications
1.API certificate
2.Stainless steel
3.Chrome plating, metal spay
4.Length:2-7 feet
5. Resistant to corrosion
Tubing pump plunger product craft :
nickle sprayed tubing pump plunger
chrome plated tumbing pump plunger
double chrome plated tubing pump plunger
Description:
The products are manufactured according to Chinese "sucker rod pump" API specifications and ISO 9001 requirements
We manufacture and supply the deep oil well sucker rod pumps according to the API 11AX specifications of THC,THM,TLE,RWAC,RWBC,RHAC,RHBC,TP,RHAM,RHBM,RHTM,RHTC,RWMB,RXBC,RXBM,RWTC and RWTM. Special pumps can be designed and manufactured such as hi-viscosity crude oil pumps,gas-proof pumps and sand-proof pumps and screw pump according to the request of users.Key parts of the pumps are made of materials with strong corrosion resistance and excellent mechanical properties according to NACE stdMR-01-76 and various well conditions
The valve balls and valve seats are made of different materials such as excellent corrosion-resisting stainless steel,tungsten carbide hardness alloy and metal ceramic
Technical sheet:
plunger mode | main technical parameter | ||||
dia (mm) | length(m) | coating | coating thickness(mm) | ||
short plunger | Ø27 |
0.9-1.2 |
spray welding |
chromeplate |
0.152-0.305 |
Ø31.75 | |||||
Ø38.10 | |||||
Ø44.45 | |||||
Ø50.80 | |||||
Ø57.15 | |||||
Ø63.50 | |||||
Ø69.85 | |||||
Ø95.25 | |||||
unit long plunger | Ø31.75 |
within-9.1m |
spray welding |
0.152-0.305 | |
Ø38.10 | |||||
Ø44.45 | |||||
Ø57.15 | |||||
Ø69.85 | |||||
Tubing pump plunger pictures:
Tubing pump plunger accesseries pictures :
Contact Us
- Puyang Zhongshi Group Co., Ltd.
- Contact nameMolly Wei Chat Now
- Phone86-371-87096211
- AddressHuayuan Road, Zhengzhou city, Henan, China, Puyang, Henan
