stainless steel hammer union FIG200,FMC WECO hammer union,butt-weld hammer union hammer union

FOB Price

US$ 1 - 2 / Set

10 Sets(Min. Order)

Port Tianjin
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other, Carbon Steel, 20# or 45# steel	Technics	Forged
Type	Union	Place of Origin	Henan, China
Model Number	ZS-GH-HU04	Brand Name	ZS
Connection	Welding	Shape	Equal
Head Code	Other

Product Description

Stainless steel hammer union FIG200,FMC WECO hammer union,butt-weld hammer union hammer union

High Pressure 1502 Steel Hammer Union
Pressure:15000psi
Connection:welding, sealin ring pipe thread
Material:20# or 45# steel

High pressure union from Puyang Zhongshi Group Co.,ltd, importing international advanced technology, is forged with high strength alloy steel, strict head treatment process can ensure that the nipple have uniform metallurgical structure and pressing ability and the materia meets ASTM and AISI standard and technology indexes conform to API Spec. 6A, the product adopts some end connections of pipeline thread, tubing thread, butt-weld and compress-seal.

FIG 100

Size		Weight	A	B	C+	TPI*	Material
(Inches)	(mm)	(LBS)	A	B	C+	TPI*	Nuts	Sub
2	50	6.25	3.94	2.84	6.25	3 MOD	Steel Forging A105
3	80	13.65	4.9	4.1	7.8	3 MOD
4	100	22	5.7	5.2	8.9	3 MOD
6	150	45.85	6.8	7.39	13.81	3 STD	Steel Casting	Steel Forging A105
8	200	66.65	7.23	9.7	16.125	3 STD	Steel Casting	Steel Forging A105
*TPI-Threads per inch.

FIG 200, 206
* socket weld and butt weld are also available

Size		Weight	A	B	C+	D**	TPI*	Material
(Inches)	(mm)	(LBS)	A	B	C+	D**	TPI*	Nuts	Sub
1	25	1.75	2.8	1.6	3.8	**	6 STD	Steel Forging A105
2	50	4.9	3.5	2.9	5.8	**	4 STD
3	80	13.25	4.5	4.1	7.8	**	4 STD
4	100	18.35	5.0	5.1	8.9	**	3 STD
6	150	46	6.61	7.41	12.8	**	3 STD	Steel Casting	Steel Forging A105
8	200	68	7.24	9.65	13.75	**	3 STD	Steel Casting	Steel Forging A105
TPI-Threads per inch. *Weld Ends-Consult Factory.

FIG 602
*SCH 160 and SCH XXH butt weld are also available

Size		Weight	A	B	C+	TPI*	Material
(Inches)	(mm)	(LBS)					Nuts	Sub
2	50	12.25	5.3	2.9	6.9	4 STD	Steel Forging 4130
*TPI-Threads per inch.

FIG 607
*SCH 160 and SCH XXH butt weld are also available

Size		Weight	A	B	C+	TPI*	Material
(Inches)	(mm)	(LBS)					Nuts	Sub
2	50	14.64	5.5	3.1	6.9	3 STD	Steel Forging 4130
*TPI-Threads per inch.

FIG 1502
*SCH 160 and SCH XXH butt weld are also available

Size		Weight	A	B	C			Material
(Inches)	(mm)	(LBS)	A	B	C			Nuts	Sub
2	50	19.5	7.06	3.15	7.6	**	3 STD	Steel Forging 4130
3	80	30.48	7.63	4.45	8.8	**	3 1/2 STD	Steel Forging 4130
