Car Rearview Mirror Parking Sensor Auto-dimming Monitor


Screen format: NTSC / PAL auto-switching system
 Display: 4.3inch true color TFT-LCD digital screen
 Resolution: 480 * 272

 Response Time: 25ms
 Input voltage: DC 12V plus or minus 20%
 2WAYS AV-INPUT
V1  are for normal CVBS video signal input, car dvd /vcd player/GPS
V2 Can be connected with camera for safe parking
When reverse the car,the rearview image
appears onto the screen automatically

options:

camera

parking sensor

auto-dimming

compass

temperature


Unit Dimension (L*D*H) 26.5*8*3.2
Qty per Export Carton 10pcs
Unit Packing: (L*W*H) 31*17.5*6.5cm
Export carton (L*W*H) 35.5*32.7*38cm
Unit Packing (G.W.) 1.3KG
Export carton (G.W.) 13KG
MOQ 100PCS
20'FT Qty 3000pcs

After - sales service
1.Sample is available for further evaluation
2. Warranty:3year
3.Offer long-term OEM/ODM service

SAFETY
1. The rear camera display is only a visual assist device when reversing the vehicle. The image on the screen may be different from the actual conditions. Always look directly with your eyes and drive carefully.
2.Backup as alow as possible since high speeds might limit your reaction time to stop the vehicle.
3.The displayable range varies depending on the vehicle loads and road conditions.
4.Do not use the rear view camera system with the tailgate open.
5.Objects under the bumper or around the bumper can not be displayed.

  Technical Specification
1.Operating Voltage9.0 -16.0 Vdc
2.Operating Temperature-40oC ~ +85oC
3.Storage Temperature-40o C~ +100oC
4.Maximum Current<450 milliamps
5.High Reflectance>70%
6.Low Reflectance6~10%
7.Time to change reflectance from 55% to 15% at 25o<6.0 seconds
8.Time to change reflectance from 15% to 55%<8.0 seconds
9. They are “hands off”, no manual adjustments are required leaving the driver free to watch the road.
10. The are variably dimming, meaning they are continually dimming and clearing to the precise level necessary to optimize vision.
11. In the darkest state, the minimum reflectance is only 7% and increases from there depending on the glare conditions.
12 Auto-Dimming Mirrors use advanced “Electrochromic” technology providing maximum glare management.
