Home > Products > Power Supply > M10-QP100,Multioutput Power Supply
M10-QP100,Multioutput Power Supply
Negotiable
/ Piece
1 Piece(Min. Order)
- xiamen shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | OEM | |
| Model Number | M10-QP100 | Output Power | 101 - 200W | |
| Output Type | Multiple | Input Voltage | Other, 110~127VAC ±10% 60Hz OR 220~240VAC ±10% 50Hz switchable | |
| Output Voltage | 0-30V | Output Frequency | 50/60Hz | |
| Output Current | 5A |
Product Description
M10-QP100,Multioutput Power Supply
Function & Benefits
- Quad independent DC outputs
- Two adjustable outputs and two fixed outputs
- Two LED to indicate the adjustable outputs' voltage
- Three symmetric outputs
- Over current proteciton on each output
Specifications
| Output1 | |
| Output Voltage | 0~30V |
| Output Current | Max. 5A |
| Line Regulation | 0.01%+3mV |
| Load Regulation | 0.01%+4mV |
| Ripple & Noise | 1mV |
| Display Accuracy | Voltmeter ±(0.2%Rdg+2digits) |
| Output2 | |
| Output Voltage | 0~±15V |
| Output Current | Max. 500mA |
| Line Regulation | 0.01%+3mV |
| Load Regulation | 0.01%+4mV |
| Ripple & Noise | 1mV |
| Display Accuracy | Voltmeter ±(0.2%Rdg+2digits) |
| Output3 | |
| Output Voltage | ±15V |
| Output Current | Max. 1A |
| Line Regulation | 1% |
| Load Regulation | 1% |
| Ripple & Noise | 5mV |
| Output4 | |
| Output Voltage | ±5V |
| Output Current | Max. 1A |
| Line Regulation | 1% |
| Load Regulation | 1.5% |
| Ripple & Noise | 2.5mV |
| Input voltage | 110~127VAC±10% 60Hz or 220~240VAC±10% 50Hz switchable |
| Dimension | 260mm(W)x160mm(H)x340mm(D) |
| Weight | 8kg |
Output1
Output Voltage 0~30V
Output Current Max. 5A
Line Regulation 0.01%+3mV
Load Regulation 0.01%+4mV
Ripple & Noise 1mV
Display Accuracy Voltmeter ±(0.2%Rdg+2digits)
Output2
Output Voltage 0~±15V
Output Current Max. 500mA
Line Regulation 0.01%+3mV
Load Regulation 0.01%+4mV
Ripple & Noise 1mV
Display Accuracy Voltmeter ±(0.2%Rdg+2digits)
Output3
Output Voltage ±15V
Output Current Max. 1A
Line Regulation 1%
Load Regulation 1%
Ripple & Noise 5mV
Output4
Output Voltage ±5V
Output Current Max. 1A
Line Regulation 1%
Load Regulation 1.5%
Ripple & Noise 2.5mV
Input voltage 110~127VAC±10% 60Hz or 220~240VAC±10% 50Hz switchable
Dimension 260mm(W)x160mm(H)x340mm(D)
Weight 8kg
