AT516,20M Ohm Precision DC Resistance Meter

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port xiamen shenzhen
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	OEM
Model Number	AT516	Display Type	Digital Only
Measuring Range	1μΩ~20MΩ	Testing Voltage	198VAC~240VAC/110V
Accuracy Class	0.05%	Operating Temperature	0~80 °C
Dimensions	264(W)mm107(H)mm350(D)mm

Product Description

AT516,20M ohm Precision DC Resistance Meter

Product Overview

AT516 DC resistance meter adopts high-performance ARM microprocessor, it is a desktop instrument that can do full-automatic real-time test with 0.05% accuracy and 1μΩ~20MΩ measurement range. With 5 digits display, 30000 reading, the maximum sampling rate is 7ms. The built-in temperature compensation interface to reduce the tolerance. The built-in 14 bins of comparator output, can setup 10 GD bins, all the comparator results can be output by Handler interface.
The standard RS-232 interface, using SCPI, it can be communicated with PC, PLC or WINCE, to efficiently complete remote control and data acquisition.

Function & Benefits

High brightness, ultra clear four-color VFD Display.
Double display: ΔABS/Δ%/Sorting Result
Zero-setting Function: Zero-Adjust for each ranges
Stores up to 30 sets of comparators HI/IN/LOW/GD/NG
Self-Calibration: Thermoelectromotive force compensation
Heavy current test mode(Open voltage <20mV)
Four-terminal resistance measurement
Beeper and brightness can be adjusted
Internal,Manual,External or Remote Trig
GPIB/USB Interface(Optional);SCPI compatible command sets

Specifications

Parameter	DC Resistance
Accuracy	0.05%
Measurement Range	1μΩ~20MΩ
Measurement current	Max current:<1A
Range	10 ranges,auto and manual
Speed	80 times/second,15 times/second,2 times/second
Display	Show/ΔABS/Δ%/Sorting Result
Display Max.	30,000
Adjustment	Short-circuit Zero-Adjust for each range. REL function
Comparator	14 build-in comparators, HI/IN/LOW/GD/NG display and output, adjustable beep and volume
Trigger	Internal ,Manual ,External or Remote Trigger
Interface	RS-232C, Handler (PLC interface)
Method	4 terminal shielding(2 check terminal and 2 driving terminal) and external shielding ground section
Others	High brightness, True-color TFT-LCD display, Keypad lock function, Data Hold function
Power supply	Voltage: 198VAC~240VAC Frequency: 50Hz Max Power: 15VA
Dimensions	Outside (mm): 264 (W)107(H)350 (D) Inside (mm): 216(W)88(H)323(D)
Weight	Weight: 4kg

Applications

Suitable for all kinds of high, middle and low resistor
Contact resistance of the switches
Contact resistance of all kinds of connector
Resistance of motor and transformer windings
Enamel-insulated wire resistance relay/switch connector contacts
PCB patterns,chip inductor DC resistance
Wire Resistance
Car,ship and plane fasten or secure resistance
