Home > Products > Pet gps tracker > zg666gps web platform tracker LK208 4400 mA battery long standby Easy to installation

zg666gps web platform tracker LK208 4400 mA battery long standby Easy to installation

FOB Price

US$ 1 - 38 / Piece

1 Piece(Min. Order)

Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Gps Tracker	Use	Automotive
Screen Size	Other, no	Function	Other, Tracking ,sos for help
Place of Origin	Guangdong, China	Brand Name	Haoday
Model Number	LK208	Warranty	1 Years

Product Description

zg666gps web platform tracker LK208 4400 mA battery long standby Easy to installation

1.Auto Report position.

2 small size,

3.Monitoring

4.60 days stanby

Summary:

Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any

remote targets by SMS or internet. The most advanced technology of GPS and AGPS dual positioning.

Applications:

Vehicle rental / Fleet management etc
Outdoor sports
Protect child / the elder/ the disabled / pet etc
Provide peace-of-mind for businessmen
Personnel Management
Criminals Tracking

Hardware Description:

Specs.

Content	Specs.
Dim.	105mm x 60mm x 20mm
Weight	144g
Network	GSM/GPRS
Band	850/900/1800/1900Mhz
GPS chip	UBLOX ( MTK6260D GSM/GPRS module)
GPS sensitivity	-159dBm
GPS accuracy	5m
Time To First Fix	Cold status 45-120s Warm status 35s Hot status 1s
Car charger	12—24V input 5V output
Wall charger	110-220V input 5V output
Battery	Chargeable changeable 3.7V 5000mAh Li-ion battery
Standby	60 days
Storage Temp.	-40°C to +85°C
Operation Temp.	-20°C to +55°C
Humidity	5%--95% non-condensing

SIM card installation

1).Open the cover, remove the screws by screwdriver,and insert GSM simcard:

2).Push back the cover and install the screws.

Battery and Charger

First time to use:Keep in charged the battery over 12 hours Please use the battery and charger provided by

the manufacturer.

After first use,the battery usually should be charged fully between 3~5 hours.

Cautions:

a: For it’s Li-ion battery, which contains harmful chemicals and may burst, please don’t bump, puncture it

violently and keep it off fire.

b: Please charge the battery in time to keep it working normally.

Startup

1).Power on gps unit:

Insert the SIM card

Turn on the unit outdoors by pressing the Power on button until the indicator is on.

In 10~40 seconds, the unit will begin to work and acquire the GSM signals as well as the GPS signal.

2).Indicators status:

3)SMS meanings:

1.Google link: URL

2.V:A GPS signal ok. V:V :No GPS signal

3.2014-04-18 02:17:15:GPS Time

4.S:000km/h: Speed of tracker

5.Bat:6:Battery Level(Range :1 ~9)

6.ID:4102000759: ID Number of GPS

7.Operations (Default password: 123456)

Change password

SMS format: pwd+old password,new password

Example: pwd123456,666888

it will reply sms: “password OK”

(Note:password should be 6 digits Arabic numbers)

Set admin phone number:

1).Add admin number:

SMS format: adm123456,0086138********

Note1:The other admin numbers should be set by the first authorized number. If the number is successfully

authorized, the unit will reply “admin ok!” in SMS.

Note2:Note:country code should be added in front of phone number)

2).Delete admin number:

SMS format: adm123456,

Example: adm123456,

Reply sms: ADM!A1:

Track on demand:

SMS format:G123456#

1).GPS Set with admin numbers: when admin numbers dials up the unit, tracker device will reply by sms,It wont reply to other numbers

2).GPS without admin numbers: Any cellphone dial up the GPS simcard,tracker device will reply by sms

locations information.

Track by GSM Location(Only for admin phone,default:closed)

Command to open :addjz=1

Command to close :addjz=0

VIEW:

PACKAGE INCLUDING :

LK208

User Manual CD

charger

USB cable
