Home > Products > warp knitting machine > High Speed Warp Knitting Machine
High Speed Warp Knitting Machine
- Shanghai or ningbo port China
 - T/T

You May Like
Product Details
| Model Number | JWHKS | Machine Type | Braiding Machine | |
| Product | Fishing Net | Material Capabilities | Yarn | |
| Certification | Other | |||
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Application:
Adopted polyester fiber and polypropylene fiber filament, polyester fiber distortion silk, mixes reels thread and other raw materials, knit usual fabric and fabric class fabric gray cloth, after reorganized the craft processing, can produce the inside and outside dress material, Simmons materials, mosquito net cloth, window blind, table, interior decoration and the industry cloth, like varnished fabric, shoes bed charge, in automobile decoration and so on.
Terry system:
- The timing construction is made up of needle bed, needle core bed, subsidence piece bed and 3 guide bars.
 - The hollow magnesium alloy molding’s widespread application, increased needle bed’s rigidity, reduces moving part’s movement inertia and the power load.
 - Crank linkage diving replaces practicality rod driving, reduced machine’s movement acceleration and the rotor inertia, reduced the machine shaking also.
 - The EBA electron delivers after system’s application, made the warp knitting operating mode more simple, strong view ability, and make the let off control more precise.

Main Datas
Needle model  | compound needle  |
Model  | e28 e32  |
Guide bar number  | 3pcs (GB1, GB2 ,GB3)  |
Working width  | 186 inches(4572mm) 218inches (5334mm)  |
Warp let-off manner  | EBA electronic let-off  |
Moving system  | adopt pattern cam, with moving –changing device  |
Density  | 6.32-70.3/cm  |
Max. speed  | 2200 rpm  |
Beam spec  | 535x535(21”x21”) 762x535(30”x21”)  |
Beam dia  | 152mm  |
Crank linkage box lubrication  | initiative pressing lubricate and oil circling constant temperature control system  |
Motor power  | 9 KW 11KW  |
Welcome to contact with us for further information!
Sample Product Photo:
