Product Details
| Place of Origin | Zhejiang, China | Brand Name | TENGLONG | |
| Model Number | GV29S |
Product Description
Specifications
GV29S AC Voltage relaywith high bright LED display
modern design
GV29S AC Voltage relay
Main parameters
Type :GV29S AC voltage relay
Rated power and voltage: AC110-240V, AC24V, 50/60HZ, DC24V ,85-110% of rated voltage
Working temperature:-10-+50°C
Output contact capacity:AC240V3A(resistive load)
Power consumption:240V50HZ≤3W
Measuring accuracy: 5% of rated voltage
Pickup setting accuracy:2.5% of rated voltage
Release setting accuracy:2.5% of rated voltage
Rated voltage:10-220V AC (it should match with voltage mutual inductor)
Absorb voltage setting range: rated voltage 25.7%
Release voltage setting range:25.7%
Usages
This product is widely applied to motor, transformer and the input circuit as a protecting component when meet the problem of over voltage or under voltage.
Features
The absorb voltage and the release voltage can be directly set;
The absorb voltage setting value, release voltage setting value and the measured voltage value can be separately selected by display the selection switch;
It is convenient to install with the features of both panel and mounting.
