Hot Sale High Quality Smd Led 3528 Datasheet
- NingBo
- T/T Credit Card
You May Like
Product Details
| Model Number | XW-3528SMD-002 | Chip Material | Other | |
| Emitting Color | Cool White | Luminous Flux(lm) | 4-5 | |
| Optical Attenuation(%) | 0.05 | Power | Other | |
| Power Dissipation | 0.1 | Color Rendering Index(Ra) | 70 | |
| Color Temperature | 2800-3200K 6000-6500K | Operating Temperature(℃) | -45, 65 | |
| Storage Temperature(℃) | -25, 80 | Place of Origin | Zhejiang, China | |
| Brand Name | XW | Certification | CE |
Product Description
Specifications
White 3528 smd led datasheet1.Factory directly
2.The lowest price
3.High quality,high lumens
4.2 years warranty
Technical Date Sheet:SMD LED 3528 datasheet
| Name | 3528 smd led |
| Lumens | 4-5lm |
| Forward Current | 20mA |
| Forward Voltage | 3.0~3.6v |
| Color Temperature | 2800-3300K,6000-6500K |
| Viewing Angle | 120° |
| Operation Temperature | -25~+80 °c |
| Storage Temperature | -40~+80 °c |
| Lifespan | 50.000hours |
| Certification | RoHS |
ABSOLUTE MAXIMUM RATING (Ta=25°C) 0.2W SMD Datasheet
Item | Symbol | Value | Unit |
Peak Forward Current | IFp | 60 | mA |
Reverse Voltage | VR | 5.0 | V |
Continuous Forward Current | IF | 20 | mA |
Recommend Operating Current | IF | 18 | mA |
Operating Temperature | Topr | -40 to 85 | °C |
Storage Temperature | Tstg | -40 to 100 | °C |
Lead Soldering Temperature | Tsol | 260°C for 3 seconds | |
CHARACTERISTICS(Ta=25°C)
Parameter | Condition | Symbol | Min | Typ | Max | Units |
Power Dissipation | IF=60mA | Pd | / | 60 | / | mw |
Correlated Color Temperature | IF=60mA | CCT | 5000 | / | 10000 | K |
Forward Voltage | IF=60mA | VF | 2.8 | 3.2 | 3.8 | V |
Reverse Current | VR=5V | IR | / | / | 10 | μA |
Chromaticity Coordinates | IF=60mA | X | / | 0.31 | / |
|
IF=60mA | Y | / | 0.33 | / |
| |
Luminous Flux | IF=60mA | ΦV | 17 | 20 | 25 | LM |
Luminous Intensity | IF=60mA | IV | 1600 | / | 2600 | mcd |
Color Rending index | IF=60mA | CRI | / | 70 | / | Ra |
Full Viewing Angle | IF=60mA | 2Φ1/2 | / | 120 | / | deg |
