Home > Products > Water-Cooled Screw Air compressor > High quality Water-cooled screw air compressor with well known screw compressor end

High quality Water-cooled screw air compressor with well known screw compressor end

FOB Price

USD $1,280 - $31,560 / Set

1 Set(Min.Order)

Port Shanghai or Ningbo
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Screw
Configuration	Stationary	Power Source	AC Power
Lubrication Style	Oil-less	Mute	Yes
Place of Origin	Zhejiang, China	Brand Name	Kaishan, kaishan
Model Number	LGS-6.2/8G-M	Dimension(LWH)	177810001300
Weight	1020kg - 6850kg	Certification	ISO9001
Warranty	1 year	After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

screw air compressor
Class2 energy efficiency
Low noise level, oil free
america usa designed & made in china
ISO9001

Supplier Assessment

Our Assessment

http://sxkaishan.en.china.cn/company_profile/capability_assessment.html

Product Description

Main Features of High quality Water-cooled screw air compressor with well known screw compressor end

Good environmental adaptability
The latest-generation high efficiency SKK Series screw rotor
Well-know screw compressor end
Interactive control system
Imported advanced microcomputer
Imported air capacity fontrol system
Imported filtration stytem
Selectable variable frequency control system

Cooling system: Large cooler and larger fan allow extreme working condition.

PLC controller:

1.User friendly control panel screen

2.Easy to operate

3.Easy to read from screen

4. 24 hours remote control function

5. Show solution message when mechine is malfunction

Technical Parameters of High quality Water-cooled screw air compressor with well known screw compressor end

Model	Motor power KW	Displacement m3/min	Working pressure Mpa	Weight kg	Size mm
LGS-6/8 LGS-5.6/10 LGS-4.8/13	37	6.0 5.6 4.8	0.8 1.0 1.3	1020	1778×1000×1300
LGS-7.5/8 LGS-6.5/10 LGS-5.6/13	45	7.5 6.5 5.6	0.8 1.0 1.3	1120	1778×1000×1300
LGS-10/8 LGHS-8.7/10 LGS-7.5/13	55	10 8.7 7.5	0.8 1.0 1.3	1800	2600×1350×1620
LGS-13/7 LGS-14.5/7 LGS-10/10 LGS-12/10	75	13 14.5 10 12	0.7 0.7 1.0 1.0	1800	2600×1350×1620
LGS-16/7 LGS-16.5/7 LGS-14.5/10 LGS-12/13	90	16 16.5 14.5 13	0.7 0.7 1.0 1.3	1900	2600×1350×1620
LGS-21/7 LGS-20/7 LGS-17/10 LGS-15/13	110	21 20 17 15	0.7 0.7 1.0 1.3	2400	2760×1680×1710
LGS-24/8 LGS-22/8 LGS-20/10 LGS-17/13	132	24 22 20 17	0.8 0.8 1.0 1.3	2500	2760×1680×1710
LGS-28/7 LGS-25/10 LGS-21/13 LGS-23/13	160	28 25 21 23	0.7 1.0 1.3 1.3	3000	2760×1680×1710
LGS-42/8 LGS-30/10 LGS-27/13	200	42 30 27	0.8 1.0 1.3	3800	3430×1950×2090
LGS-45/7 LGS-38/10 LGS-33/13	250	45 38 33	0.7 1.0 1.3	4500	3430×1950×2090
LGS-58/7 LGS-48/10 LGS-42/13	315	58 48 32	0.7 1.0 1.3	5800	4000×2000×2100
LGS-64/7 LGS-54/10 LGS-48/13	355	64 54 48	0.7 1.0 1.3	6200	4000×2000×2100
LGS-82/7 LGS-68/10 LGS-59/13	450	82 68 59	0.7 1.0 1.3	6600	4200×2200×2100
LGS-104/7 LGS-90/10 LGS-78/13	560	104 90 78	0.7 1.0 1.3	6850	4200×2200×2100
LGS-140/7	800	140	0.7	9700	4200×2200×2100

Product Overviews

Pictures of Price of High quality Water-cooled screw air compressor with well known screw compressor end

Packaging & Shipping

Packaging for High quality Water-cooled screw air compressor with well known screw compressor end : wooden case, also according to your request.

Shipping: 15-30 days by Fedex, UPS, EMS, TNT, etc

Certifications
