Home > Products > Diesel Portable Screw Compressor > Kaishan LGCY -22/13 air compressor diesel engine
Kaishan LGCY -22/13 air compressor diesel engine
US$ 10,580 - 85,000
/ Set
1 Set(Min. Order)
- ShangHai or NingBo
- T/T L/C D/P D/A Credit Card
You May Like
-
Kaishan LGCY -21/13 portable diesel engine driven air compressors
-
KAISHAN LGCY-7.5/7 screw air compressor,air compressor screw
-
0.7 MPA 12M3/MIN Diesel Screw compressor air compressor price list
-
Portable Diesel LGCY22/13 Air Compressor Kaishan brand price list
-
KAISHAN Brand Mining LGY-5.6/13 High efficiency and energy saving Moter driven portable screw air compressor
-
Hot Sale! Diesel Screw Silent Air Compressor price list(LGCY-13/13)
Product Details
| Condition | New | Type | Piston | |
| Configuration | Stationary | Power Source | AC Power | |
| Lubrication Style | Lubricated | Mute | Yes | |
| Place of Origin | Zhejiang, China | Brand Name | KaiShan | |
| Model Number | LGCY-22/13 | Dimension(L*W*H) | 3400*1800*1500 | |
| Weight | 1700 | Certification | ISO9001 | |
| Warranty | 1year | After-sales Service Provided | Overseas third-party support available |
Product Description
Diesel mobile screw air compressor
Diesel mobile screw air compressor, is widely used in highway, railway, water conservancy, mining, shipbuilding, construction, energy, military and other industries.
The annual output of substantial growth, the movable screw air compressor market share be way ahead. Kaishan brand diesel mobile screw compressor performance is reliable, the variety is complete, the power range of 37~300kW, the exhaust volume coverage to 30m3/min, the discharge pressure of up to 2.2MPa.
Portable air compressor LGCY-6/7Advantages
1. Simple and flexible travelling system
2. High efficiency and cost-effective
3. Enviromental friendly
4. Superior electric controllor system
5. Safe and stable operation system
6. Low noise and environmental friendly
The spcification of LGCY Serious portable diesel screw air compressor.
| Model | Displacement | Exhaust pressure | Reted power | Weight | Size |
| m3/min | MPa | KW | kg | mm×mm×mm | |
| LGCY-6/7 | 6 | 0.7 | YCD4B22-95,70kW | 1400 | 3750×1920×1700 |
| LGCY-7.5/7 | 7.5 | 0.7 | YC4D80-K20,58kW | 1850 | 3900×1920×1700 |
| LGCY-8.5/14 | 8.5 | 1.4 | 4BTA3.9-C125,93kW | 1900 | 3900×1920×1900 |
| LGCY-9/7 | 9 | 0.7 | YC4D95Z-K20,70kW | 1850 | 3900×1920×1700 |
| LGCY-9/14 | 9 | 1.4 | YC6B150Z-K20,110KW | 2380 | 4080×1980×2350 |
| LGCY-9/14.5 | 9 | 1.45 | YC6B150Z-K20,110kW | 2380 | 3970×1940×2350 |
| LGCY-10/7 | 10 | 0.7 | YC4D95Z-K20,70kW | 1900 | 3900×1920×1700 |
| LGCY-10/10 | 10 | 1 | 4BTA3.9-C125,93kW | 1900 | 3900×1920×1900 |
| LGCY-12/7 | 12 | 0.7 | 4BTA3.9-C125,93kW | 2050 | 3900×1920×1900 |
| LGCY-12/7A | 12 | 0.7 | YC4A125Z-T10,92kW | 2050 | 4000×1980×1900 |
| LGCY-12/10 | 12 | 1 | YC6B150Z-K20,110kW | 2380 | 4080×1980×2350 |
| LGCY-12/12 | 12 | 1.2 | EQ6BT5.9-C160,118kW | 2380 | 4080×1980×2350 |
| LGCY-13/17 | 13 | 1.7 | 6CTA8.3-C215,158kW | 2380 | 3780×1980×2350 |
| LGCY-13/13 | 13 | 1.3 | 6BTA5.9-C180,132kW | 2750 | 3450×1520×2220 |
| LGCY-13/13A | 13 | 1.3 | YC6A190Z-T10,140kW | 2750 | 3450×1520×2220 |
| LGCY-15/13 | 15 | 1.3 | WD415.23,166kW | 3350 | 3380×1650×2500 |
| LGCY-15/13A | 15 | 1.3 | YC6A240-20,177kW | 3350 | 3380×1650×2500 |
| LGCY-16/13 | 16 | 1.3 | 6CTA8.3-C215,158kW | 3700 | 3980×1800×2450 |
| LGCY-16/17 | 16 | 1.7 | 6CTA8.3-C260,194kW | 3700 | 3650×1800×2500 |
| LGCY-17/7 | 17 | 0.7 | 6BTA5.9-C180,132kW | 3050 | 3380×1640×2350 |
| LGCY-17/14.5 | 17 | 1.45 | 6CTA8.3-C260,194kW | 3700 | 3980×1800×2450 |
| LGCY-18/17 | 18 | 1.7 | 6CTA8.3-C260,194kW | 3700 | 3980×1800×2450 |
| LGCY-18/19 | 18 | 1.9 | CUMMINS 6CTA8.3-C260 | 3700 | 3980*1800*2450 |
| LGCY-18/19A | 18 | 1.9 | YC6M260L-K20 | 3700 | 3980*1800*2450 |
| LGCY-21/35 | 21 | 3.5 | CUMMINS QSZ13-C500 | 5000 | 4600x1950x2600 |
| LGCY-21/35A | 21 | 3.5 | YC6K500L | 5000 | 4600x1950x2600 |
| LGCY-22/8 | 22 | 0.8 | 6CTA8.3-C260,194kW | 4000 | 4580×1950×2600 |
| LGCY-22/14 | 22 | 1.4 | YC6M340L-K20,250kW | 4500 | 4580×1950×2600 |
| LGCY-22/14K | 22 | 1.4 | 6LTAA8.9-C325,239kW | 4500 | 4580×1950×2600 |
| LGCY-22/13S | 22 | 1.3 | WD615.46,266kW | 4500 | 4250×1950×2500 |
| LGCY-22/20 | 22 | 2 | NTA855-P400,298kW | 4850 | 4450×1950×2650 |
| LGCY-22/20K | 22 | 2 | 6LTAA8.9-C360,265kW | 4500 | 4600×1950×2850 |
| LGCY-22/20A | 22 | 2 | YC6M340L-K20 | 4850 | 4600*1950*2850 |
| LGCY-26/20 | 26 | 2 | NTA855-P400,298kW | 4850 | 4450×1950×2650 |
| LGCY-26/20 | 26 | 2 | CUMMINS 6LTA8.9-C360 | 4500 | 4600*1950*2850 |
| LGCY-26/25 | 26 | 2.5 | CUMMINS QSZ13-C500 | 5000 | 4600x1950x2600 |
| LGCY-26/25A | 26 | 2.5 | YC6K500L | 5000 | 4600x1950x2600 |
| LGCY-26/35 | 26 | 3.5 | CUMMINS QSZ13-C550 | 6800 | 4700*2100*2850 |
| LGCY-26/35A | 26 | 3.5 | YC6K550L | 6800 | 4700*2100*2850 |
| LGCY-27/10 | 27 | 1 | YC6M340L-K20,250kW | 5000 | 4600×1950×2850 |
| LGCY-27/20 | 27 | 2 | YC6M395L-K20 | 4850 | 4600*1950*2850 |
| LGCY-27/22 | 27 | 2 | CUMMINS NTA855-P400 | 4850 | 4600*1950*2850 |
| LGCY-33/25 | 33 | 2.5 | CUMMINS QSZ13-C550 | 6800 | 4700*2100*2850 |
| LGCY-33/25A | 33 | 2.5 | YC6K550L | 6800 | 4700*2100*2850 |
| LGCY-33/35 | 33 | 3.5 | CUMMINS KTA19-P630 | 6800 | 4700*2100*2850 |
| LGCY-33/35A | 33 | 3.5 | PETER CULLER C-18ACERT | 6800 | 4700*2100*2850 |
| LGCY-39/25 | 39 | 2.5 | CUMMINS KTA19-P630 | 6800 | 4700*2100*2850 |
| LGCY-39/25A | 39 | 2.5 | PETER CULLER C-18ACERT | 6800 | 4700*2100*2850 |
Our Company:
1. Shanxi Kaishan Mechanical & Electrical Equipment Co., Ltd. is located in a
Beautiful ancient City - Xi'an. Since founded more than 10 years ago, our
company has accumulated much experience in the business of air compressors
and drilling rig machines
2. National Free-inspection Product,Have passed ISO9001 certification.
3. Good Service, competitive price, high quality, fast shipping and perfect after
sale service.
Welcome to visit our factory and would like to start the cooperation with you in the near future.
Thank you for browsing our products!If you are interested in our products please do not hesitate and feel free to contact with me!
Wesite:
Mobile.phone:86-15129884623
Office phone:86-029-88631990
