Product Details
| Condition | New | Type | Grinder | |
| Product Type | Other, all of goods | Place of Origin | Sichuan, China | |
| Brand Name | JSDL | Model Number | jsdl-syj6 | |
| Voltage | 380V | Power(W) | 6-160KW | |
| Dimension(L*W*H) | subject to custmer`s requests | Weight | different models different weight | |
| Certification | CE,ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Special designed 43 um ultrafine lab pulverizing mill laboratory powder mill
Feature:
it is a small experimental device specially designed for colleges and scientific research department, equipment has the advantages of small volume, compact structure, convenient assembly and disassembly. Break through the particle acceleration technology, greatly improve the grinding efficiency, and reduce energy consumption, avoid over crushing.
1 can reach 2-74Um particle size, narrow particle size distribution and no large particles
2 crushing by material collision, can process Mohs hardness of 1-10 particles, reduce abrasion, product without iron contamination
3 reasonable cooling flow field in the grinding process, due to the rapid expansion of the air flow and air temperature is reduced, processing and especially suitable for heat sensitive, low melting point materials
4, optimize the structure of equipment, improve equipment performance, can dissociation agglomeration of ultrafine powder, polymer dispersed effective.
5 original classification flow technology, can obtain the crushing efficiency and tight size distribution best, smash granularity can be regulated arbitrarily between 1-74um, the smallest can reach sub micron, reduce material loss, can achieve the basic body cavity crushing material completely crushed, few equipment inner wall residual, no dead angle, easy to clean, fully meet the GMP standard
6 original special jet and classification flow processing technology, suitable for adhesion material
7 can perform species material mixing pulverizing, has good mixing function
8 operation in sealed negative pressure, no environmental pollution
Technical parameter:
Model | Max feed size | Discharging size | Manufacture capacity | Install power | gas consumption |
JSDL-SYJ6 | <1mm | 2-80um | 500-5000g/h | <6-8.5kw/380v | 1m3/min |
JSDL-SYJ7 | <1mm | 2-80um | 500-5000g/h | <6-9kw/380v | 1m3/min |
JSDL-SYJ8 | <1mm | 2-80um | 0.5-10kg/h | <18-20kw/380v | 1m3/min |
Chengdu Our Trading Co.,Ltd is a trade and industry integrated company which established in 2008 with abundant exporting experience. With the company developed, we have 2 factories, one is located in Chengdu and another is in Mianyang.
Our main products are micronizer jet mill, micronizer impact mill, air classifier, inter gas protective equipment etc.
Application of pulverator:
Processing materials in many fields, such as: health food raw material, herbal medicine, pesticide, cosmetic, chemical materials, mining materials, metallurgy, waste resource and scientific research project etc.
We believe that our perfect products and excellent services will establish a win-win business relationship with you.
cooperation machine show:
SUPPORT
We can not only provide the good machines, but also wholeheartedly provide the comprehensive for our clients. The series of professional technology service will make you have an excellent product experience.
After-sales service support
After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the perfect goods trading services, until the product you purchased properly to your hands.
We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc.
Technological support
JSDL has been largely adopting new technologies, new techniques and high-tech equipments. And JSDL also has strict and effective quality control system.
JSDL insists on providing clients with overall solutions from equipment recommendation to debugging and installation, worker training, technical support and maintenance.
