2016 3g GPS Vehicle Tracker System Software

Sinocastel IDD-213E/N (3G GPS TRACKER)
GSM OBD II GPS Tracker

IDD-213GL is a quad-band GSM, 3-axis accelerometer and OBD module integrated OBD GPS Tracker for 9-36V vehicles. It could read OBD parameters from car ECU and capture GPS data then transmit to the backend server for remote diagnostic and tracking purpose.

-- Fleet management and Vehicle Tracking

-- Car service shops/car delears
-- Insurance company
-- Car rental company

Mechanical

OBD interface: 16 pin standard OBD II

Configuration interface: Mini-USB

SOS button interface: MMCX

SAE J1850 PWM

SAE J1850 VPW

ISO 9141-2

ISO 14230-4

ISO 15765-4

SAE J1939

Max.: <200mA   13.8/27.6VDC

Average: <150mA   13.8/27.6VDC

Configuration cable

OBD II extension cable

6-Pin deutsch wiring harness

SOS button

CE   E-Mark (Pending)

-40℃ ~ +85℃

Sinocastel Co.,Ltd is a subsidiary of China Aerospace Science and Technology Corporation (CASC). As one of the co-founders  of China GPS Association, CASTEL Group has more than 15 years experiences in GPS and LBS application, wireless, communication and access, and are engaged in R&D and manufacturing and provisioning of customized integrated solutions.

1. What is OBD&OBDII?
OBD(On-board diagnostics)is an automotive term referring to a vehicle's self-diagnostic and reporting capability. OBD systems give the vehicle owner or repair technician access to the status of the various vehicle sub-systems. Modern OBD implementations use a standardized digital communications port to provide real-time data in addition to a standardized series of diagnostic trouble codes, or DTCs, which allow one to rapidly identify and remedy malfunctions within the vehicle.
OBD-II is an improvement over OBD-I in both capability and standardization. The OBD-II standard specifies the type of diagnostic connector and its pinout, the electrical signalling protocols available, and the messaging format. It also provides a candidate list of vehicle parameters to monitor along with how to encode the data for each.

2. What is the obd gps tracker?
gps tracker intergrate with OBD protocol.

3. What is the different OF 213GL, IDD-213E and IDD-213N?
213GL for GSM sim card,213E&213N for WCDMA sim card, 213E for Europ market,213N for North America market.

4. Your obd gps tracker support or doesn't support SIM card?
All obd serial product Support SIM card.

5.How does the device work?
download PCTOOL from Sinocatel website, use USB cable connect computer set APN and others data, plug and play with vehicle.

6. What is the Frequency of the simcard?GSM and WCDMA?
GSM Frequency: 850/900/1800/1900MHz, WCDMA Frequency:800/850/900/2100(Europ),800/850/1700/1900(North America)

7. Does your tracker have SMS alerts?
Yes, SMS alerts from phone.

8.Does your system have demo test account?
yes, test account:demotest, password:123456.

9. Does your system free to use?
free half year, get pay after half year, can provide the charge list if you need.

10. Does your system have smartphone APP?
yes, APP name UUAID, download from wesbite.
