FCC & PTCRB Passed OBD GPS Tracking system
US$ 25 - 90
/ Piece
10 Pieces(Min. Order)
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Type | Gps Tracker | Use | Automotive | |
| Screen Size | Other, Web/Android/IOS App | Place of Origin | Guangdong, China | |
| Brand Name | Sinocastel | Model Number | IDD-213G | |
| Warranty | 12 Months, One year from the receipt date |
Product Description
[ FCC & PTCRB Passed OBD GPS Tracking System ]
IDD-213G is our best designed quad-band, 3-axis accelerometer integrated J1939 & J1708 Heavy Duty Trucks OBD GPS Tracker. It could read engine parameters and Error code from car ECU and GPS information from U-blox GPS module; then send all data to the backend server (web/ IOS/ Android APP) for remote diagnostic and tracking purpose.
---------------------------------------------------------- Features ----------------------------------------------------------
- Compact design, Plug-and-play,
- Support 9-36V vehicles of OBDII, J1939 J1708 protocols, like MAN, Mercedes Benz, Buses
- Real time gps tracking and history trace playback
- Trip Fuel consumptions monitoring
- DTCs monitoring
- Car parameters reading including RPM, speed, ECT, MAF, TP etc
- Driving behavior alarm for the hard acceleration, hard deceleration, idle engine, speeding etc
- Low voltage monitoring
--------------------------------------------------------- Parameters ---------------------------------------------------------
| Mechanical | Size | 63mm (L) x 50mm (W) x 28mm (H) | |
| Weight | 50g | ||
| Data transmission | GPRS/SMS | ||
| Storage | 2MB FLASH,up to 24,000 GPS data storage | ||
| OBD protocol | SAE J1850 PWM | ||
| SAE J1850 VPW | |||
| ISO 9141-2 | |||
| ISO 14230-4 | |||
| ISO 15765-4 | |||
| SAE J1587/J1708/SAE J1939 | |||
| Working Voltage | 9-36VDC | ||
| Backup battery | 3.7V/120mAH | ||
| GPS | Channels: 50 | ||
| Sensitivity: -160dBm | |||
| Accuracy: 5m CEP | |||
| Time to first fix: | |||
| Cold start: <32s (typ.) | |||
| Hot start: <1s (typ.) | |||
| GSM | Frequency: 850/900/1800/1900MHz | ||
| Network protocol: Embedded TCP/IP stack | |||
| Sensitivity: -107dBm@850/900MHz | |||
| -106dBm@1800/1900MHz | |||
| Output power: Class 4 (2W)@850/900MHz | |||
| Class 1 (1W)@1800/1900MHz | |||
| 3 axis Accelerometer | +/-2g, +/-4g, +/-8g, +/-16g, driving behavior detection | ||
| Antenna | GSM | Internal | |
| GPS | External | ||
| Accessories | G-Mouse | ||
| Driving behavior monitor | |||
| Configuration cable | |||
| OBD II extension cable | |||
| Wiring harness for heavy duty | |||
| Certification | FCC/CE/E-mark | ||
