Megapixel HD IP IR Speed Dome Camera (360 Degrees Rotation. Eeffective Night Vision 100-150 Meters)

Image sensor :

1/3″Panasonic CMOS(1.3 megapixel)

Effective pixel:

1280(H)×1024(V)

Signal system:

PAL/NTSC

Scanning mode:

Progressive scanning

Horizontal resolution:

800TVL(output 720P)

Frame rate:

SXGA(1280×1024) / 30fps

Built-in lens:

18X Zoom (F1.5, 4.8~86.4mm)

Day and night switch:

IR-CUT filters auto switch in day / night

Iris control:

Auto iris

Focusing system:

Digital high-speed auto focusing

Min. Illumination:

Color: 1.2 Lux / B/W: 0.05 Lux

Synchronization system:

External synchronization

Signal to noise ratio:

> 50db(AGC OFF)

White Balance:

Auto/indoor/outdoor/manual

automatic gain:

OFF/low/medium/high

 Back light compensation:

OFF /Back light compensation/restrain strong light

Sharpness:

OFF/Adjustable

The noise reduction:

3D digital noise reduction/2D digital noise reduction/ smart noise reduction, noise level is adjustable

Electronic shutter speed:

Automatic, 1/50 ~ 1/10,000/S

Fog function:

Auto digital anti- fog function,Three adjustable

Automatic slow shutter:

OFF / ON

WDR:

OFF/Low / Middle / High

Adjustable brightness:

Support

Screen freezing:

Support

screen rotating:

Horizontal mirroring / vertical mirroring/rotation

Film effects:

Support

Motion detection:

Support

Privacy mask:

Support 8 area

Edge illumination compensation:

Support

OSD:

Chinese/English OSD

Protocol type:

PELCO-D,baud rate 2400-38400bps

Interface:

36 Pin FPC(the same as the Hitachi)

Video output::

Digital signal ( Y/Cb/Cr 4:2:2)

Supply voltage:

DC/12V

Working environment:

-25℃ TO 60℃, 20% TO 90% RH

Power Consumption:

4.3W(motor is not activated) / 5.6W(Motor activation)

Size:

90.3mm (L) x 58mm (W) x 49mm (H)
