230V/400V Motor Electric

Specifications

AOWEI NMRV REDUCER - electrical motors

Detailed Product Description

Y2 series Electric motor electric

Advantage:

1. Utilise IP55 enclosures, others request

2. Multiple feet locations

3. Aluminium frame, end shields and base

4. High strength cable gland

5. Shaft key and protector supplied

6. Superior paint finish

7. Motors made to heavy duty service factors

8. Can be made with stainless steel shaft

9. Motors made for continuos S1 duty

10.Utilise Vacuum impregnated Class B or Class F insulation

11. Others insulation on request

12. High performance and efficiency

Feature:

Y2 series three-phase asynchronous motors,developed with new techniques,are renewed and upgrading products based on Y series motors.

Y2 series motors are in total-sealed design and fan cooled type,squirrel cage type and novel in design and nice in appearance,compact structure.lower noise,high efficiency,large torque,excellent starting performance,easy maintaince,etc. this series motor adopt F class insulation and designed as the insulation system addessing method in accordance of international practice.

Y2 series motors can be widly applied to various of driving equipments such as machine tools, blowers pumps,gear boxes,compressors,teansporters,agricultural machines etc.

Operating conditons:

altitude:no higher than 1000meters from sea level

rated voltage:380+/-5%

rated frequency:50HZ or 60HZ

Insulation class :F

Coolong type:IC411

Duty type:S1.

Date for reference:

       Warehouse for Spare parts

 Workshop
