Abs Pipe Plastic Extruder Machine Planetary Screw Barrel

Base Material

1)38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11)
3)4Cr5MoSiV1(JIS SKD-61)  4)42CrMo(AISI 4140)

Bimetallic Alloy Materials

1)Fe-based alloy  2)Ni-based alloy/Deloro alloy
3)Co-based alloy  4)NiCo-based alloy
5)Tungsten carbide/Wolfram carbide

Double-alloy level

Level A - containing Tungsten of 40%

Level B - containing tungsten of 25%

Level C - containing tungsten of 9.5%

Surface Treatment

Heat Treatment

High Frequency Treatment

Nitriding treatment(120 Hours)

Depth of Nitrided Layer: 0.5-0.8 mm

Hardness of Nitrided Layer: 900-1020Hv (HRC56°-65°)

Hard Chrome Plating treatment:

Thickness of Hard Chrome Plating Layer: 0.05-0.10mm

Hardness of Hard Chrome Plating Layer: ≥950HV

Nickel alloy plating.treatment:

Bimetallic Barrel/Cylinder: Centrifugal Casting (Inlay Alloy)

Bimetallic Screw: Plasma Alloy Coating Spraying

Depth of Bimetallic Layer: >2mm

Hardness of Bimetallic Layer: HRC55°-72°

Basic information

Roughness of the surface:Ra0.4um

Linearity of the screw: ≤0.015mm

Linear axis limit: ≤0.02mm

Hardness after Hardening & Tempering: HB240-280

Fragility of Nitration:≤Two class

Material Application

1)General Plastics

2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc

3)PA + GF(Glass Fiber)

4)Flame-resistant Reinforced Plastics

5)Modified Engineering Plastics

6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc

General Terms

Means of transport: Ocean,Air,Express

Production time: About 25 days after we receive the deposit and lead time will different according to the order quantity!

Our products advantages

1)High productivity        2)Wonderful plasticizing

3) low energy consumption  4)Wearable and Durable

5)Fast and On time delivery  6)Best customer service!

Zhejiang Zhongyang Screw Manufacturing Co.,Ltd is a professional and dedicated designer,manufacturer,rebuilder and distributor of screws,barrels and assembly parts for plastic and rubber machines.With our business philosophy of quality oriented and customers foremost,Zhongyang keeps improving to offer excellent products and services to customers.Our commitment to customer satisfaction is priority number one at ZHONGYAG.

Working Attitude---Every employee at ZHONGYANG is a good team player.We have enthusiasm on our jobs and we do our jobs seriously and responsibly,every employee wants to do the best to contribute to our company growth at ZHONGYANG.

Factory Strength---- We are located in Jintang town,Zhoushan city of Zhejiang provice.Our factory occupies 10,000M2 and is well equipped with kinds of advanced CNC processing machines.With 12 years industrial know-how and experience,we have grown to be a specialist in the industry. We have our own professional teams in the sales, design, production, inspection and customer service areas.And we are always ready to help you with your specific needs.

Quick Response---- Our sales team is well-trained with good qualifications and is passionate and ambitious,we respond quickly and efficiently.

Technical Capabilities ----- We have a group of experienced and creative engineers,they help to solve customers technical problems with their expertise and they do excellent jobs in designing new screw and barrel to achieve superior performance of the screw and barrel.

Good Products ----- As an ISO certified enterprise since 2006,we established complete quality control system and step by step,we implement the system thoroughly from the first production process to final products now.Every production process in under strict inspection to ensure that only qualified products are sent to our customers.

• Quality always comes first. Our experienced workers pay attention to every tiny procedure during the production and inspection, to ensure the precision of every dimension.
• Service makes us outstanding. Our sales people are trained on the products every day. They are always ready to answer your questions and offer the best solutions in fluent English at any time.
• Provide an easier working way. With 6 years export experience, we offer before-sales, prouction update, after-sales one stop service, which makes an easier way to work with us. We welcome you to visit our factory at any time!

Welcome to contact us

If you are looking for a reliable screw barrel supplier,you won't be wrong to choose us!
