Large Capacity Cassava Starch Dehydrator & Vacuum Filter
US$ 1 - 999,999
/ Set
1 Set(Min. Order)
- SH/QD
- T/T
You May Like
-
China Cassava Cage Cleaning Machine Conveyer
-
Vacuum Dehydrator & Cassava Starch Production Machine
-
Hydrocyclone Machine/hydrocyclone Starch Separator/fine Fiber Separating Machine
-
Cassava Starch Milk Dehydrator/starch Vacuum Filter
-
Tapioca Powder Production Lines Cassava Rasper
-
Tapioca Starch Production Lines Cassava Slicer Rasper
Product Details
| Place of Origin | Henan, China | Brand Name | JINGHUA | |
| Model Number | XDL6 | Type | Grain Processing Equipment |
Product Description
Main features of starch equipment:
- Combing the lastest technology and years experience into a whole
- Fully stainless steel for parts contacting with material, compact structure and nice design
- Speed of rotating drum can be adjusted according to actual site
- Material unloaded through blade, which is made of high rigid alloy and can be adjusted
- Stirrer's running frequency can be adjusted
- Continuous adjusting for fluid-level control
- Low energy consumption, small area, easy operation and stable running
- Widely used for dewatering of starch slurry in starch processing
Main technical parameters:
Model | XDL6 | XDL12 | XDL20 | XDL36 |
Vacuum degree (Mpa) | 0.04~0.07 | 0.04~0.07 | 0.04~0.07 | 0.04~0.07 |
Content of solid (%) | ≥60 | ≥60 | ≥60 | ≥60 |
Filter area (m2) | 6 | 12 | 20 | 36 |
Feeding density (Be0) | 16~17 | 16~17 | 16~17 | 16~17 |
Capacity (t/h) | 2.6 | 4 | 6 | 10 |
Power (kw) | 1.5 | 3 | 4 | 5.5 |
Drum rotary speed (r/min) | 0~7.9 | 0~7.9 | 0~7.9 | 0~7.9 |
Weight (kg) | 1600 | 3000 | 4000 | 7200 |
Dimension (mm) | 2245x2100 x2013 | 3425x2312 x2213 | 4775x2312 x2213 | 5910x3063 x3095 |
