Home > Products > Automatic screen printer > Automatic Digital Silk Screen Printing Machine
Automatic Digital Silk Screen Printing Machine
- Shenzhen
- Credit Card
You May Like
-
4 Colors 14 Stations Automatic Textile Screen Printing Machine
-
Automatic Silk Screen Printing Machine
-
Factory Supply Automatic Silk Screen Printing Machine
-
Factory Provided Automatic Silk Screen Printing Machine
-
Automatic Screen Printing Machinery
-
Automatic 8-color 24-station With 7 Flash Dryer Screen Printing Machine
Product Details
| Condition | New | Place of Origin | Guangdong, China | |
| Brand Name | Hengxin | Model Number | HS-120AL-1 | |
| Usage | Label Printer, Other, Label Printer, Automatic digital silk screen printing machine | Automatic Grade | Automatic | |
| Voltage | 380v/220v | Gross Power | 0.75 Kw | |
| Dimensions(L*W*H) | 2800*1300*1900mm | Weight | 850kg | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | No overseas service provided |
Product Description
HS-120AL-1 Auto digital silk screen printing machine, auto screen printing machine for plastic bottle, full automatic single color cylinder / cylindrical screen printing system, auto screen printing machine
Specification:
Subject surface | Oval | Round |
Max speed | 4000pcs/hr | 3600pcs/hr |
Max print length | 120mm | 300mm |
Max print wide | 250mm | 250mm |
The size of print | Semi meter: Φ 25-Φ 260mm | diameter: Φ 25-120mm |
Length: 60-300mm | Length: 60-300mm | |
The power of UV lamp | 4Kw/unit | |
UV air draft power | 0.2KW | |
reduction gearbox Conveyer proportion | 1: 7.5 | |
Single motor power | 0.75KW | |
The power of bottle lifter vacuum motor | 0.5KW | |
Vacuum supply | 500 mm Aq | |
Flame treatment fuel | LPG | |
air supply | 6Bar | |
Air consumption | 730 Liter/Min | |
Application:
The HS-120AL-1 is specially designed for single colour printing different patterns on the objects with round shape or oval shape. It is suitable for plastic, glass, ceramics, metal, etc. Reliability and speed make the HS-120AL-1 ideal for off-line or in-line production.
Features:
1. The machine is specialized design for print the round and oval bottles, with easy operation and stable.
2. Feeding machine can load product to the screen printing machine automatically...Fully automatic feeding, flame treatment, UV screen printing and UV curing.
3. It is mechanical conveyer, touch control panel operation, easy to operation the machine. Fast adjustment, easy operation. Fast printing, speed: 4000PC/hr.
4. Fully automatic, the machine will alarm without product loading and no printing without product. It can save energy.
5. All components and control system are from Germany and Japan, guarantee the quality of the print.
6. It is suitable for print round/oval product printing such as the cosmetic bottles, drink bottles, cans ect.
