Shandong HONGDA Truck mounted Concrete Mixer 9m3 STEYER

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	TIELISHI	Model Number	9m3, HDT5255GJB
Certification	ISO CCC	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

Truck-mounted Concrete Mixer		Parameter
Complete vehicle Parameters		Unit	9m3
	Model		HDT5255GJB
	Total length	mm	9200
	Total Width	mm	2490
	Total height	mm	3800
	Chassis model		STEYERKING ZZ1256N3846C/
	Overall weight	kg	25000
	Curb weight	kg	13500
	Wheel base	mm	3800+1350
	Front tread	mm	2041
	Rear tread	mm	1830
	Tyre model		11.00-20, 12.00-20
	Front overhang	mm	1560
	Rear overhang	mm	2490
	Min. Turning Radius	m	9.8
	Max. speed	Km/h	75
	Steering device (GERMANY)		ZF8098
	Oil consumption per 100 kilos(under limited conditions)	L	34
Engine	Engine model		WD615.96, WD615.96E
	Cylinder number and arrangement		Linear 6-cylinder
	Engine max. output power	kw	276/2200
	Engine max. output torque	N.M	1350/1100-1600
Working device	Mixing Drum Volume	M3	14.7
	Mixing cubage	M3	9
	Mixing Drum Slope Angle	%	13.5
	Mixing Drum Rotating Speed	r/min	0-14
	Feeding speed	M3/min	≥3.5
	Discharge speed	M3/min	≥1.5
	Slump	mm	100-230
	Surplus rate	%	<0.5
	Water tank Capacity	L	400
