Waterproof floor tile backer board
USD $4 - $20
/ Square Meter
200 Square Meters(Min. Order)
- SHANGHAI/NINGBO
- Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Olingen | |
| Model Number | OBB-1 |
Product Description
Insulation & waterproofing solutions !!!
Waterproof floor tile backer board
Product Overviews
Product structure:
Made of high-performance waterproof extruded polystyrene, it has a 0.75mm coating on either side comprising a glassfiber mesh embedded in a polymer cement mortar.
Standard dimensions and weight :
Thickness(mm) | Weight(kg/m²) | Length by width(mm*mm) |
6 | 2,7 | 1220 x 600 |
10 | 2,9 | 1220 x 600 |
12 | 3,0 | 2440 x 600 |
20 | 3.1 | 2440 x 600 |
30 | 3,3 | 2440 x 600 |
50 | 4,2 | 2440 x 600 |
The board has the following tolerances:thickness:± 2mm width:± 2mm length:± 3mm
We do OEM as well. Welcome to make an enquiry and we will give you prompt response!
Main applications:
Used as a watertight layer on walls and floors in houses, hotels and other wet areas such as bathroom, shower room.
1.Attaching to masonry,concrete or plaster
2.Screwing onto laths and supports
3.Concrete floors
4.Timber floors
5.Underfloor heating
6.Bathtubs and shower tray surrounds
7.Vanities and shelving
8.Pipe coverings
Product Display
Project Cases
FAQ
Why do I need Olingen BOARD?
Because Olingen BOARD will save you money by acting as a very efficient insulation barrier. It reflects the heat upwards into the floor tile instead of allowing the heat to warm up the concrete slab below. Besedes, it not only has the function of heat insulation and strong waterproofness, but also provides a base for the ceramic tile.
How does Olingen BOARD compare to plasterboard?
It doesn’t there really is no comparison. Standard plasterboard offers approximately 1/6th the U value of an equal thickness of Olingen BOARD. and yet is approximately 7 times heavier. When used in wet areas, such as bathrooms or showers,Olingen BOARD is totally waterproof whereas plasterboard will absorb water unless it is of the waterproof variety which will cost considerably more.
Compare a few characteristics of Olingen BOARD against plasterboard
1. 1/7th the weight of Plasterboard
2.waterproof, ordinary plasterboard is not.
3.(10mm) has a U value of 2.7 against 12.8 W/M2 K of 12.5mm
What are its benefits?
Being extremely strong, Olingen BOARD can be used as a structural element in the floor. It will not only take a load of 30 tonnes per square metre, so it's ideal for putting under your floor, but it keeps your floor warmer, longer, by not allowing heat to penetrate down into the concrete substrate below. In addition ,Olingen tile backer board good water resistance so that they are widely used in wetroom and bathroom.
What thickness Olingen BOARD do I need?
The thicker the Olingen BOARD the better the heat insulation, but obviously if you have an existing floor that you want to insulate, you may well be governed by the thickness you can add to the floor because of the height from the finished floor to the underside of your door. Even by using 6mm Olingen BOARD you will notice the benefit of insulating with Olingen BOARD .Generally speaking,,6mm and 12mm are used for floor while thicker than 20mm are usually for wall partition.
How do I fix Olingen BOARD to walls?
The board can be either fixed to timber battens with screws and screw cups or fixed directly to brick or block walls by drilling, plugging and screwing the boards to the wall. If the wall is to be plaster finished, the joints should be reinforced with a plaster scrim
:
