Product Details
| Brand Name | APS | Model Number | API Sucker rod and Polish rod | |
| Type | Sucker Rod | Machine Type | Drilling Tool | |
| Certification | API | Material | Other, Chromium, Alloy steel | |
| Processing Type | Forging | Use | Well Drilling |
Product Description
Hollow sucker rod/Solid sucker rod/Polish rod and Pony rod in API spec. oil drilling operation with high quality
l SUCKER ROD
-Hollow/Solid Sucker Rod
-Sinker bar (Heavy Weight Sucker Rod)
-Polish Rod
-Surface Anti-Corrosive Sucker Rod
A sucker rod is a steel rod, threaded at both ends, used in the oil industry to join together the surface and downhole components of a reciprocating piston pump installed in an oil well. The pump jack is the visible above-ground drive for the well pump, and is connected to the downhole pump at the bottom of the well by a series of interconnected sucker rods.
-Grade : Grade K, D, KD etc.
-Couplings:
----Standard class T coupling: 5/8”; 3/4”; 7/8”; 1”; 1 1/8”.
----Class T slim hole coupling: 5/8”SH; 3/4”SH; 7/8”SH; 1”SH; 1 1/8”SH.
----Class SM coupling: 5/8”; 3/4”; 7/8”; 1”;
----Sub-Coupling: 5/8”×3/4”; 3/4”×7/8”; 7/8”×1”; 1”×1 1/8”.
Materials & Size Specifications
Type | Sucker Rod | Polish Rod | Heavy Weight Sucker Rod | |
Material Class | Class D | 20CrMoA | As Requirements | As Sucker Rod |
30CrMoA | ||||
35CrMoA | ||||
Class K | 20Ni2Mo | |||
Class KD | 20CrNiMo | |||
AISI4720 | ||||
4330V | ||||
OD Range | 5/8”, 3/4”, 7/8”, 1” | 1 1/8”; 1 1/4”; 1 1/2”. | 1 1/4”; 1 3/8”; 1 1/2”; 1 5/8”; 1 3/4” | |
Length Range | 2Ft; 4Ft; 6Ft; 8Ft; 10Ft; 12Ft; 25Ft; 26.4Ft; 30Ft. | 16Ft; 22Ft; 25Ft; 26Ft; 30Ft. | 2Ft; 4Ft; 6Ft; 8Ft; 10Ft; 12Ft; 25Ft; 26.4Ft; 30Ft. | |
Grade and Mechanical Properties of the sucker rod
| No. | Grade | Tensile Strength Rel(Mpa) | Yield Strength Rm(Mpa) | Percentage Elongation A(%) | Contraction Percentage Of Area Z(%) |
| 1 | C | 620-795 | ≥415 | ≥13 | ≥50 |
| 2 | K | 620-795 | ≥415 | ≥13 | ≥60 |
| 3 | D | 795-965 | ≥590 | ≥10 | ≥50 |
| 4 | KD | 795-965 | ≥590 | ≥10 | ≥50 |
| 5 | HL | 965-1195 | ≥795 | ≥10 | ≥45 |
| 6 | HY | 965-1195 | —— | —— | —— |
