Multifunction and Automatic Fish Smoking Machine With Low Price

FOB Price

US$ 10,000 - 30,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Sausage
Application	smoking for meat	Automatic Grade	Automatic
Production Capacity	≤1000kg/stove	Brand Name	Deric fish smoking machine
Model Number	DR-SM1000 fish smoking machine	Voltage	380V or as you need
Power(W)	6kw	Dimension(LWH)	129015101700*
Weight	900kg	Certification	CE
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Multifunction and Automatic Fish Smoking Machine with Low Price

Features and Advantages of fish smoking machine:

1. It has functions of steaming, frying, boiling and smoking. It is easy to operate.

2. Excellent insulation and sealing performance. It has low energy consumption and high efficiency.

3. It consist of the stove body, heating system, circulated air system, electronic control and so on.

4. There is alarm when the processing is finished or breakdown happens.

5. The electric control system: it automatically control, monitor and show every step. It can save 99 programs.

Technical Data of fish smoking machine:

Model	DR-SM100	DR-SM250	DR-SM500	DR-SM1000
Productivity	≤100 kg/stove	250 kg/stove	500kg/stove	1000kg/stove
Power	6kw	7.5kw	13.5kw	27kw
High pressure steam pressure	0.3~0.6 Mpa	0.3~0.6 Mpa	0.3~0.6 Mpa	0.3~0.6 Mpa
Low pressure steam pressure	0.1~0.2 Mpa	0.1~0.2 Mpa	0.1~0.2 Mpa	0.1~0.2 Mpa
Smoke introduction ignition	≤15 min	≤15 min	≤15 min	≤15 min
Inner stove temperature	95°C	95°C	95°C	95°C
Hydraulic pressure	0.2Mpa	0.2Mpa	0.2Mpa	0.2Mpa
Standard trailer (mm)	1000×1030×800	1000×1030×1980	1000×1030×1980	1000×1030×1980
Main engine size (mm)	1290×1510×1700	1290×1510×2600	2420×1510×2600	4765×1510×2600
Installation dimensions (mm)	4000×2200×3400	4000×2200×3400	6000×2200×3400	8000×2200×3400
Weight	900kg	1400kg	1800	2600

Pictures of Smoked Meat
