Hydraulic Cnc Guillotine Plate Shearing Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Anhui, China
Brand Name	Hudong	Model Number	QC11Y-6*3200-E20
Certification	ISO9001:2000,CE	Warranty	12 months after saling
After-sales Service Provided	Engineers available to service machinery overseas	Voltage	optional

Product Description

Hydraulic cnc guillotine plate shearing machine

Properties and characters:

1.It is the second generation of hydraulic plate shearing machine.
2.Machine frame and knife rest are welded integral. Vibration eliminates stress. Precision is kept well.
3.The advanced integrated hydraulic system is reliable.
4.Adopt three-point support rolling guide to eliminate gas between supports and improve shearing quality.
5.Gap between blades is adjusted with hand-operated wheels, so it is quick, exact and convenient.
6.The four rectangular blades all can be used for a long time.
7.The up knife rest adopts interior inclining structure for falling conveniently and improving precision.
8.It has the function of shearing by stages.
9.It has the lighting function.
10.Back stop is controlled with E18 numerical control system.

Technical data:

No.			value		unit	remark
1	Max cutting thickness			6	mm	σb≤450N/mm
2	Max cutting width			3200	mm
3	Throat depth			100	mm
4	Shearing angle			0.5-1.5	°
5	Strokes time			16-45	Min-1
6	Max stroke volume of up knife			100	mm
7	Max shearing force			140	KN
8	Max compressive force feeding				KN	Change with the load
9	Max working force of system			12	MPa
10	Adjustment of back gauge			10-600	mm
11	Oil pump	model		25MCY14-1B
		flow		32	ml/r
12	Master motor	model		Y132M-4
		power		7.5	kW
		Rota e speed		1440	r/min
13	dimension	length		3730	mm
		width		2075	mm	No including the former ruler
		height		1970	mm
