IG3 Horizon 4cil Rail 3.0 Ohm (Type E3)

FOB Price

US$ 20 - 30 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

IG3 Horizon 4cil Rail 3.0 Ohm (Type E3)
1.Excellent silent running
2.Stable injection flow
3.Simple maintenance
4Factory/OEM

IG3 Horizon 4cil Rail 3.0 Ohm (Type E3)

Product Description

Advantages:

(1)Good performance even with dirty LPG and without fitting protective filter;

(2)Stable injection flow,simple maintenance and compact overall dimensions;

(3)Excellent silent running.

1.Item	IG3 HORIZON 2.8 Ohm / 2.0 Ohm 4CYL Injectors Rail
2.Operating voltage	DC 10.8-14.4V
3.Operating pressure	0.5bar-2.0bar
4.Maximum pressure	4.5bar
5.Opening Time	Type E3(2.8Ohm±15%):2.5ms±5% Type E2(2Ohm±15%):2.0ms±5%
6.Closing Time	Type E3(2.8Ohm±15%):2.0ms±5% Type E2(2Ohm±15%):2.0ms±5%
7.leakage rate	≤15cc/h
8.Nozzle hole range	1.0-3.5mm(0.25mm step)
9.Inlet gas fitting	Rubber hose Φ10mm / Φ12mm / Φ16mm
10.Outlet gas fitting	Calibrated nozzles M8x1;external Φ7mm
11.Approval	ECE 67R-01 / 110R-00
12.T range	-20°C-120°C for LPG; -40°C-120°C for CNG
13.Coils parameter	(A)Type E3: 2.8Ohm±15% Type E2:2.0Ohm±15%; (B)Color:Red;Blue;Black;or Customized
14.Electrical connection	Two ways Amp/Delphi connector(1.5mm)
15.Suitable fuel	LPG(Liquefied petroleum gas) and CNG(Compressed natural gas)
16.Samples	Available,delivery time is 1-3days.
17.Quality control	All goods will be 100% inspected before dispatching.
18.R&D ability	OEM available,open new molds according to your samples or drawings.

Packaging & Shipping

1.Packaging	A:Common Packing: 1PC + Plastic bag + Label + Inner Box+Export Carton 50PCS/Carton B:Customized Packing: OEM Label, Inner Box,etc
2.Transportation	(1)By sea,by air,or by express(TNT,Fedex,UPS,DHL,Aramex,EMS etc) (2)We will do best to get good freight cost for you.
3.Payment Terms	T/T, Paypal,Western Union,L/C,Escow
4.Delivery Time	According to your order quantity.
5.Company Type	Factory and trade integration,years of export experience;

Production Equipment

Injector Rail Manual
