Home > Products > Fiber Optic Pigtail > 0.9mm Fiber Optic Pigtail-SC/PC

0.9mm Fiber Optic Pigtail-SC/PC

FOB Price

USD $0.5 - $2.7 / Piece

5 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	JINGKON
Model Number	Fiber Optic Pigtail-SC/PC

Company--Manufacturer
Products type--ST,SC,FC,LC,MTRJ,DIN--SM,MM
Quality--ROHS,
Insertion loss -0.2dB

0.9mm Fiber Optic Pigtail-SC/PC

Description		Patchcord
Item NO.	Test Item		Unit	Standard & Requirement
1	Appearance		/	No crack, No scar, good conformability
2	Ferrule polished end		/	No scar, No spot
3	Insertion loss		dB	SM≤0.2
4	Return loss		dB	PC≥60,
5	Radius of curvature		nm	10 ≤ r ≥25
6	Curvature eccentricity		um	<50
7	Fiber core undercut		nm	<50
8	Fall apart test		dB	H=1M,connector free-falling 5 times Insertion loss change< 0.1,Return loss change< 5, No flab, No distortion
9	Repetitiveness		dB	Insertion loss change< 0.1,Return loss change< 5
10	Insert & pull out		/	Max: 2KG
11	Tensile strength		dB	0- 10KG per minutes Insertion loss change< 0.1,Return loss change< 5, No flab, No distortion
12	Anti-contortion		dB	2.5Kg ,200times, 10times/minutes, ±80° Insertion loss change < 0.1,Return loss change< 5, No flab, No distortion
13	Package		/	Clean, Correctitude, No dirt
14	Allowable bending radius		mm	15mm

·Certificate:
